FULLY MODULAR DESIGN
All the black flat cables are modular design. Installing only the cables you need to reduce clutter, to increase the airflow and to improve the chassis thermal performance.
80 PLUS GOLD CERTIFIED
80 Plus Gold certified ensures to deliver 90% efficiency at 50% load. The better power efficiency leads to less power waste, less heat and less fan noise. And with the support of Intel processors, it will save more energy and more money.
HIGH QUALITY JAPANESE CAPACITORS
The main capacitors are high quality Japanese capacitors, to produce the efficient performance and to ensure the longer reliability.
120MM SMART HYDRAULIC BEARING (HYB) FAN
The fan speed is adjusted according to the automatic power detection and will stop when the system is idle or under low load (less than 20% load). The Hydraulic Bearing fan provides longer and more stable life time.
SINGLE +12V RAIL
Single +12V rail provides the best power output, stability and compatibility for the hardware. It provides the easiest way to install the power cable. And it is the best design for overclocking.
PROTECTION
In order to make sure the entire computer system to operate stably under any conditions, we not only added protection designs such as OCP, OTP, OVP, OPP, UVP and SCP, but also ensured the stable operation of your system through the safety certification of various countries.
| Tootja | GIGABYTE |
| Tootekood | GP-P750GM |
| EAN | 4719331551759 |
| Google link | lisainfo |
| Garantiiaeg | 36 kuud |
| .: Üldised andmed :. | |
| Tootja koduleht | https://www.gigabyte.com/Power-Supply/GP-P750GM#kf |
| .: Üldised omadused :. | |
| ATX-versioon | 2.31 |
| .: Disain :. | |
| Keskmine tõrkeintervall (MTBF) | 100000 h |
| Toote värv | Black |
| Jahutuse tüüp | Aktiivne |
| Otstarve | PC |
| Toote värv | Must |
| Keskmine tõrkeintervall (MTBF) | 100000 hours |
| .: Toimimine :. | |
| Power supply unit (PSU) form factor | ATX |
| Toiteploki (PSU) standard | ATX |
| .: Pesad & liidesed :. | |
| EPS toitepistik (4+4 pinn) | Jah |
| Flopiajami kaabli pikkus | 12 cm |
| SATA toitekaabli pikkus | 150,600 mm |
| Välise (Molex) toitekaabli pikkus | 120,500 mm |
| PCI Express toitekaabli pikkus | 60 cm |
| CPU power cable length | 600 mm |
| CPU toitekaabli pikkus | 60 cm |
| Emaplaadi toitekaabli pikkus | 61 cm |
| PCI Expressi pistmik | Jah |
| ATX-toitepistmik (20 + 4 kontakti) | Jah |
| CPU-toitepistik (4 + 4 kontakti) | Jah |
| Emaplaadi toitepistmik | 20+4 pin ATX |
| Flopidraivi toitepistmik | 1 |
| Kaabelduse tüüp | Täielikult modulaarne |
| PCI Expressi toitepistmikud (6 + 2 kontakti) | 4 |
| SATA-toitepistmike arv | 8 |
| Välisseadmete (Molex) toitepistmikud (4 kontakti) | 4 |
| Võimsus ja energiatarve | |
| Sisendvool | 12-6 A |
| Võimsusteguri korrigeerimise (PFC) tüüp | Aktiivne |
| Sisendsagedus | 50 - 60 Hz |
| PFC (Võimsusteguri korrigeerimine) tüüp | Active |
| AC-sisendpinge | 100 - 240 V |
| AC-sisendsagedus | 50 - 60 Hz |
| Hoide aeg | 16 ms |
| Tõhusus | 90 protsenti |
| Toite kaitsefunktsioonid | Ülevool, Ülevõimsus, Ülepinge, Ülekütmine, Lühis, Alapinge |
| Jahutus | |
| Ventilaatori paiknemine | Ülaosa |
| Ventilaatori läbimõõt | 12 cm |
| Ventilaatorite arv | 1 fan(s) |
| .: Tehnilised andmed :. | |
| Koguvõimsus | 750 W |
| Funktsioonid | |
| Vahelduvvoolu pinge | 100 - 240 V |
| Mudeli originaalnimi | GP-P750GM |
| Logistika andmed | |
| Harmonized System (HS) kood | 84733020 |
| .: Kaal ja mõõtmed :. | |
| Laius | 150 mm |
| Brutokaal | 2.63 kg |
| Laius | 150 mm |
| Sügavus | 140 mm |
| Kõrgus | 86 mm |
| Mõõtmed (l x s x k) | 150 x 140 x 86 mm |
| Sügavus | 140 mm |
| Kõrgus | 86 mm |
| .: Pakendi andmed :. | |
| Kaablid kaasa arvatud | CPU,PCIe,Peripheral (Molex),SATA |
| Max kogus transpordipakendis | 5 |
| Pakendi maht | 0.008137 cubm |
| Transpordipakendi kaal | 13.16 kg |
| Transpordipakendi kõrgus | 29 cm |
| Transpordipakendi laius | 23 cm |
| Transpordipakendi sügavus | 61 cm |
| ◁ SERTIFIKAADID ▷ | |
| 80 PLUS sertifikaat | 80 PLUS Gold |
| Muud andmed | |
| Hold time | 16 ms |
| Harmonized System (HS) code | 84733020 |
| EPS power connector (4+4 pin) | Jah |
| Floppy disk drive cable length | 120 mm |
| Motherboard power cable length | 610 mm |
| Product colour | Black |
| Summary | GIGABYTE P750GM. Total power: 750 W, AC input voltage: 100 - 240 V, AC input frequency: 50 - 60 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 61 cm, SATA power cable length: 150,600 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Cables included: CPU, PCIe, Peripheral (Molex), SATA |
| Peripheral (Molex) power cable length | 120/500 mm |
| SATA power cable length | 150/600 mm |
| PCI Express power cable length | 600 mm |
| Unit Calculated Weight | 2.63 kg |
| Product Net Weight | 2 kg |
| Unit Calculated Volume | 0.008137 cubm |
| Units per Shipping Box | 5 |
| Unit Box Width | 0.12 |
| Unit Box Length | 0.255 |
| ATX version | 2.31 |
| Fan location | Top |
| Unit Box Height | 0.21 |
| ATX power connector (20+4 pin) | Jah |
| Cooling type | Active |
| CPU power connector (4+4 pin) | Jah |
| Floppy drive power connector | 1 |
| Motherboard power connector | 20+4 pin ATX |
| Number of SATA power connectors | 8 |
| PCI Express connector | Jah |
| PCI Express power connectors (6+2 pin) | 4 |
| Peripheral (Molex) power connectors (4-pin) | 4 |
| Power Factor Correction (PFC) type | Active |
| Power protection features | Over current/Over power/Over voltage/Overheating/Short circuit/Under voltage |
| Purpose | PC |
| 80 PLUS Certification | 80 PLUS Gold |
| Cabling Type | Fully-Modular |
| Cooling System | 12cm fan |
| Efficiency | 90 % |
| Fan Diameter | 120 mm |
| Mean time between failures (MTBF) | 100000 h |
| PSU | ATX 2.31 |
| PSU Output Power | 750 Watts |
| Total power | 750 W |
