Support PCIe Gen 5.0 graphics card
The UD850GM PCIE 5.0 has a 16-pin connector and comes with a high-quality native 16-pin cable that allows you to use the PSU with a PCIe Gen 5.0 graphics card. This cable can support up to 600 watts of power to the graphics card.
ULTRA DURABLE
Inherit the product design spirit of GIGABYTE Ultra Durable, thus introducing a variety of high-quality materials and designs. Ultra Durable combines high-quality main Japanese capacitors, enhanced thermal solution, 120mm smart hydraulic bearing (HYB) fan, and six circuit protection designs. It provides consumers with a high-quality and stable power supply, and can be used for a long time.
HIGH QUALITY JAPANESE CAPACITORS
The main capacitors use high quality Japanese capacitors to produce the efficient performance and ensure the longer reliability.
ENHANCED THERMAL SOLUTION
Compared with the standard thermal solution, we have enlarged the heatsink by about 200% or more, and optimized the airflow. The heat dissipation performance is increased by more than 10%, thus prolonging the service life of the components.
120MM SMART HYDRAULIC BEARING (HYB) FAN
The fan speed is adjusted according to the automatic power detection and stops when the system is idle or under low load (less than 20% load). The hydraulic bearing fan provides longer and more stable life time.
PROTECTION
In order to make sure the entire computer system to operate stably under any conditions, we not only added protection designs such as OCP, OTP, OVP, OPP, UVP and SCP, but also ensured the stable operation of your system through the safety certification of various countries.
FULLY MODULAR DESIGN
All the black flat cables are modular design. Installing only the cables you need to reduce clutter, to increase the airflow and to improve the chassis thermal performance.
80 PLUS GOLD CERTIFIED
80 Plus Gold certified ensures to deliver 90% efficiency at 50% load. The better power efficiency leads to less power waste, less heat and less fan noise.
PLENTIFUL POWER SUPPLY
The +12VHPWR and the +12V can provide a total of 850W power output. The +12VHPWR can provide up to 600W for the latest PCIe Gen 5.0 graphics card.
COMPACT DESIGN
With the help of engineers' excellent design capabilities and heat dissipation technology on various hardware products, and the use of higher quality materials, GIGABYTE has reduced the length of the power supply to an amazing 140 mm, so it can be easily installed in any chassis without space constraints.
| Tootja | GIGABYTE |
| Tootekood | GP-UD850GMPG5 |
| EAN | 4719331553104 |
| Google link | lisainfo |
| Garantiiaeg | 36 kuud |
| .: Üldised andmed :. | |
| Tootja koduleht | https://www.gigabyte.com/Power-Supply/GP-UD850GM-PG5/sp#sp |
| .: Üldised omadused :. | |
| Müratase | 40 dB |
| .: Disain :. | |
| Toote värv | Black |
| Keskmine tõrkeintervall (MTBF) | 100000 hours |
| .: Toimimine :. | |
| Power supply unit (PSU) form factor | ATX |
| Võimsus ja energiatarve | |
| Sisendvool | 12 - 6 A |
| Sisendsagedus | 50 - 60 Hz |
| PFC (Võimsusteguri korrigeerimine) tüüp | Active |
| Jahutus | |
| Ventilaatorite arv | 1 fan(s) |
| .: Tehnilised andmed :. | |
| Warranty period | 5 year(s) |
| Compliance certificates | CCC/CE/Federal Communications Commission (FCC)/RoHS |
| Funktsioonid | |
| Vahelduvvoolu pinge | 100 - 240 V |
| .: Kaal ja mõõtmed :. | |
| Netokaal | 2.5 kg |
| Brutokaal | 2.68 kg |
| Laius | 150 mm |
| Sügavus | 140 mm |
| Kõrgus | 85 mm |
| Mõõtmed (l x s x k) | 150 x 140 x 86 mm |
| .: Pakendi andmed :. | |
| Pakendi tüüp | Box |
| Kaablid kaasa arvatud | CPU,PATA,Peripheral (Molex),SATA |
| Max kogus transpordipakendis | 1 |
| Pakendi maht | 0.006552 cubm |
| Transpordipakendi kaal | 2.678 kg |
| Transpordipakendi kõrgus | 12 cm |
| Transpordipakendi laius | 21 cm |
| Transpordipakendi sügavus | 26 cm |
| Muud andmed | |
| Cable tie(s) included | Jah |
| Fan location | Top |
| Hold time | 16 ms |
| Number of PATA power connectors | 3 |
| Unit Box Height | 0.12 |
| Unit Box Length | 0.26 |
| Unit Box Width | 0.21 |
| CnCode | 85044095 |
| Units per Shipping Box | 1 |
| Unit Calculated Volume | 0.006552 cubm |
| Product Net Weight | 2.5 kg |
| Unit Calculated Weight | 2.68 kg |
| Summary | GIGABYTE GP-UD850GM PG5. Total power: 850 W, AC input voltage: 100 - 240 V, AC input frequency: 50 - 60 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 61 cm, SATA power cable length: 150,600 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Cables included: CPU, PATA, Peripheral (Molex), SATA |
| Product colour | Black |
| Motherboard power cable length | 610 mm |
| Peripheral (Molex) power cable length | 200/600 mm |
| SATA power cable length | 150/600 mm |
| PCI Express power cable length | 700 mm |
| Maximum input current (@220V) | 12 A |
| PCI Express power connectors (16-pin) | 1 |
| ATX power connector (20+4 pin) | Jah |
| Cooling type | Active |
| CPU power connector (4+4 pin) | Jah |
| Illumination | Ei |
| Motherboard power connector | 20+4 pin ATX |
| Number of SATA power connectors | 8 |
| PCI Express connector | Jah |
| PCI Express power connectors (6+2 pin) | 4 |
| Peripheral (Molex) power connectors (4-pin) | 2 |
| Power Factor Correction (PFC) type | Active |
| Power protection features | Over current/Over power/Over voltage/Overheating/Short circuit/Under voltage |
| Purpose | PC |
| 80 PLUS Certification | 80 PLUS Gold |
| Cabling Type | Fully-Modular |
| Combined power (+12V) | 850 W |
| Combined power (+3.3V) | 105 W |
| Combined power (+5V) | 105 W |
| Combined power (+5Vsb) | 15 W |
| Combined power (-12V) | 3.6 W |
| Cooling System | 12cm fan |
| Efficiency | 90 % |
| Fan Diameter | 120 mm |
| Max output current (+12V) | 70.8 A |
| Max output current (+3.3V) | 20 A |
| Max output current (+5V) | 20 A |
| Max output current (+5Vsb) | 3 A |
| Max output current (-12V) | 0.3 A |
| Maximum input current (@110V) | 6 A |
| Mean time between failures (MTBF) | 100000 h |
| PSU | ATX 3.0 |
| PSU Output Power | 850 Watts |
| Total power | 850 W |
