UPS|EATON|1600 Watts|2000 VA|OnLine DoubleConvertion|Desktop/pedestal|9E2000I
AL1
E1
AC
Vajad toodet suuremas koguses või püsitellimust?
Võta ühendust meie klienditoega info[at]digipood.eu
Kuumakse al. 24.45 €. Taotle järelmaksu ostukorvis.
The Eaton 9E UPS constantly monitors power conditions and regulates voltage and frequency thanks to the double conversion topology. Eaton 9E UPS can power more servers than most similar UPS because of a 0.8 power factor.
- Get clear information on the UPS’ status and measurements (load level, battery level, input/output voltage and frequency) on a single screen with the new LCD interface
- Easily communicate with the UPS through USB, RS232 serial or over the network with the optional network card (Network-MS). Relay cards or Modbus cards are also available
- Integrate 9E into all software environments. The Eaton 9E is delivered with Eaton’s Intelligent Power™ Software and is compatible with all major OS including advanced integration in VMware vCenter and Microsoft Hyper-V
- Wide input voltage range will minimize the battery usage and help to extend battery lifetime
- The internal bypass allows service continuity in case of an internal fault
- Extend runtime as you like by adding up to 4 external battery modules (EBM) for 2kVA and above. For extra-long runtime, XL models with internal supercharger are also available at 3kVA
.: Üldised andmed :.
- Tootja koduleht
- https://powerquality.eaton.com/Products-services/Backup-Power-UPS/9E-1-3kVA.aspx?cx=41&GUID=482418BF-1164-410A-AEB9-A0ED9FA7A642
.: Üldised omadused :.
- Müratase
- 40 dB
- Puhvertoiteallika topoloogia
- Online UPS
.: Disain :.
- Toote kuju
- Tower
- Toote värv
- Black
- Kujutegur
- Tower
- Kujutegur
- Torn
- Toote värv
- Must
.: Pesad & liidesed :.
- Seerialiides
- Jah
- Jadaliidese tüüp
- RS-232
- AC-väljundi tüüp
- C13 pistikut, C19 pistikut
- AC-väljundite arv
- 6 vahelduvvoolu kontakt
- Elektripistik
- C13 pistikut
- Jadaportide kogus
- 1
- RS-232 portide arv
- 1
- USB port
- Jah
.: Aku & Toiteallikas :.
- Tüübipärane varundamisaeg poole koormusega
- 12 min
- Tüübipärane varundamisaeg täiskoormusega
- 4 min
Võimsus ja energiatarve
- Output frequency
- 50/60 Hz
- Väljundvõimsuse potentsiaal
- 2 kVA
- Sisendi tööpinge (minimaalne)
- 100 V
- Sisendsagedus
- 50/60 Hz
- Sisendi tööpinge (maksimaalne)
- 300 V
- Väljundvõimsus
- 1600 W
- Tõhusus
- 91 protsenti
- Väljundi tööpinge (maksimaalne)
- 240 V
- Väljundi tööpinge (minimaalne)
- 208 V
- Väljundvõimsus
- 1600 W
.: Tehnilised andmed :.
- Väljundsagedus
- 50/60 Hz
Logistika andmed
- Kogus transpordikasti kohta
- 1
Töötingimused
- Kasutamistemperatuur (T-T)
- 0 - 40 °C
.: Pakendi andmed :.
- Max kogus transpordipakendis
- 1
- Pakendi maht
- 0.07514 cubm
- Transpordipakendi kaal
- 23.15 kg
- Transpordipakendi kõrgus
- 46 cm
- Transpordipakendi laius
- 33 cm
- Transpordipakendi sügavus
- 49.5 cm
◁ SERTIFIKAADID ▷
- Ohutus
- IEC/EN 62040-1
- Sertifikaat
- IEC/EN 62040 -2, CE, CB report (TUV)
Tehnilised andmed
- Serial interface
- Jah
- Safety
- IEC/EN 62040-1
- Serial interface type
- RS-232
- Input operation voltage (min)
- 100 V
- AC outlet types
- C13 coupler/C19 coupler
- AC outlets quantity
- 6 AC outlet(s)
- Power plug
- C13 coupler
- Unit Box Height
- 0.46
- Unit Box Length
- 0.495
- Unit Box Width
- 0.33
- CnCode
- 85044095
- Unit Calculated Volume
- 0.07514 cubm
- Product Net Weight
- 22.4 kg
- Unit Calculated Weight
- 23.1 kg
- Summary
- Eaton 9E 2000I. UPS topology: Double-conversion (Online), Output power capacity: 2 kVA, Output power: 1600 W. AC outlet types: C13 coupler, C19 coupler, Power plug: C13 coupler, AC outlets quantity: 6 AC outlet(s). Typical backup time at full load: 4 min, Typical backup time at half load: 12 min. Form factor: Tower, Product colour: Black. Certification: IEC/EN 62040 -2, CE, CB report (TUV)
- RS-232 ports
- 1
- Serial ports quantity
- 1
- UPS topology
- Double-conversion (Online)
- Certification
- IEC/EN 62040 -2, CE, CB report (TUV)
- Desktop/pedestal
- Jah
- Efficiency
- 91 %
- Input frequency
- 50/60 Hz
- Input operation voltage (max)
- 300 V
- Input ports
- Single, IEC320 C14
- Output operation voltage (max)
- 240 V
- Output operation voltage (min)
- 208 V
- Output power capacity
- 2 kVA
- Output power capacity, VA
- 2000 VA
- Output power capacity, W
- 1600 Watts
- Output power connector type
- IEC 320 C13
- RS232
- 1
- Topology
- OnLine DoubleConvertion
- Typical backup time at full load
- 4 min
- Typical backup time at half load
- 12 min
- USB
- 1
Tehnilised andmed
- Toote kaal
- 22,4 kg
- Laius
- 330 mm
- Netokaal
- 22.4 kg
- Brutokaal
- 23.1 kg
- Laius
- 330 mm
- Sügavus
- 190 mm
- Kõrgus
- 399 mm
- Mõõtmed (l x s x k)
- 399 x 330 x 190 mm
- Sügavus
- 190 mm
- Kõrgus
- 399 mm
- Toote kaal
- 22400 g
