ASUS PRIME H610M-K D4 Intel H610 LGA 1700 Mikro ATX

Muud näitajad

Number of displays supported

2

Compatible processor series

Intel® Celeron®/Intel® Core™ i3/Intel® Core™ i5/Intel® Core™ i7/Intel® Core™ i9/Intel® Pentium®/Intel® Pentium® Gold

BIOS type

UEFI AMI

ATX Power connector (24-pin)

Jah

EPS power connector (8-pin)

Jah

Memory slots type

DIMM

Motherboard chipset family

Intel

Number of chassis fan connectors

1

Number of COM connectors

1

Supported memory types

DDR4-SDRAM

Memory channels

Dual-channel

Front panel audio connector

Jah

S/PDIF out connector

Jah

CPU fan connector

Jah

Number of SATA III connectors

4

PCI Express x16 (Gen 3.x) slots

1

Number of M.2 (M) slots

1

Drivers included

Jah

Supported storage drive types

HDD & SSD

Maximum number of SMP processors

1

Supported storage drive interfaces

M.2,SATA

Processor manufacturer

Intel

RGB LED pin header

Jah

RGB LED pin ots

Jah

USB 3.2

2

USB 3.2 Gen 1 (3.1 Gen 1) A-tüüpi portide hulk

2

USB 3.2 Gen 2 (3.1 Gen 2) C-tüüpi portide hulk

0

USB 3.2 Gen 1 (3.1 Gen 1) pistmikud

1

USB 3.2 Gen 1 (3.1 Gen 1) C-tüüpi portide hulk

0

USB 3.2 Gen 2 (3.1 Gen 2) konnektorid

0

PCI-Express 4.0 16x

1

PCI Express x16 (Gen 4.x) slots

1

PCI Express x16 (Gen 4.x) pilud

1

Unit Box Height

0.26

Unit Box Length

0.27

Unit Box Width

0.055

CnCode

84733020

ECC сompatibility

Non-ECC

ECC ühilduvus

Mitte-ECC

Unit Calculated Volume

0.004788 cubm

Unit Calculated Weight

0.99 kg

Summary

ASUS PRIME H610M-K D4. Processor manufacturer: Intel, Processor socket: LGA 1700, Compatible processor series: Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9,.... Supported memory types: DDR4-SDRAM, Maximum internal memory: 64 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, SATA, Supported storage drive types: HDD & SSD, RAID levels: 0, 1, 5, 10. Ethernet interface type: Gigabit Ethernet. Component for: PC, Motherboard form factor: micro ATX, Motherboard chipset family: Intel

Harmonized System (HS) code

84733020

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

2

USB 3.2 Gen 1 (3.1 Gen 1) connectors

1

12V power connector

Jah

Kogus transpordikasti kohta

10

USB 3.2 Gen 2 (3.1 Gen 2) A-tüüpi portide hulk

0

Harmonized System (HS) kood

84733020

Component for

PC

COM-pistmike arv

1

Toetatud ketaste tüübid

HDD & SSD

Toote kaal

842 g

Tootja koduleht

https://www.asus.com/Motherboards-Components/Motherboards/PRIME/PRIME-H610M-K-D4/

Transpordipakendi kaal

0.856 kg

Transpordipakendi kõrgus

26.5 cm

Transpordipakendi laius

5 cm

Transpordipakendi sügavus

27.5 cm

Kõrgus

51 mm

Kõrgus

51 mm

Toote kaal

842 g

HDMI-versioon

2.1

Ethernet interface type

Gigabit Ethernet

Ethernet LAN (RJ-45) ports

1

HDMI versioon

2.1

Headphone outputs

1

Microphone in

Jah

Motherboard chipset

Intel H610

Toetatud ekraanide arv

2

Unbuffered memory

Jah

VGA (D-Sub) ports quantity

1

Windows operating systems supported

Windows 10 x64/Windows 11 x64

BIOS memory size

128 Mbit

Number of memory slots

2

Processor Socket

LGA 1700

Raid Levels

0/1/10/5

Supported memory clock speeds

2133/2400/2666/2800/2933/3000/3200 MHz

USB 2.0 connectors

1
