NET CAMERA 4MP IR DOME WIFI/IPC-HDBW1430DE-SW-0280B DAHUA

.: Üldised andmed :.

Tootja koduleht

https://www.dahuasecurity.com/products/All-Products/Network-Cameras/Wireless-Series/Wi-Fi-Series/4MP/IPC-HDBW1430DE-SW

Seadme tüüp

IP security camera

.: Disain :.

Kokkuvõte

Dahua Technology Mobile Camera DH-IPC-HDBW1430DE-SW. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired & Wireless. Mounting type: Ceiling, Product colour: White, Form factor: Dome. Angle of rotation: 355°, Lens viewing angle, horizontal: 90°, Tilt angle range: 0 - 75°. Sensor type: CMOS, Optical sensor size: 25.4 / 3 mm (1 / 3"). Detect distance: 68 m, Observe distance: 27.2 m, Recognize distance: 13.6 m

Kujutegur

Dome

Toote värv

Valge

.: Mälu :.

Paigaldatud operatiivmälu

64 MB

Integreeritud kaardilugeja

Jah

Ühilduvad mälukaardid

MicroSD (TransFlash)

.: Audio :.

Sisseehitatud mikrofon

Sisseehitatud

.: Kaamera :.

Automaatfookus

Jah

.: Võrgustumine :.

Web browser

Jah

WiFi

Jah

WiFi-standardid

802.11b/802.11g/Wi-Fi 4 (802.11n)

Ethernet LAN

Jah

Bluetooth

Ei

.: Aku & Toiteallikas :.

Toiteallika tüüp

DC,PoE

.: Salvestusruum :.

ROM capacity

16 MB

Antenn

Antenni tüüp

Väline

Antennide arv

1

Pildisensor

Progressiivne skaneerimine

Jah

Objektiivi süsteem

Lens viewing angle, horizontal

90 °

Öövaatluse funktsioon

Öönägemine

Jah

Toide

Toitenõuded

DC 12V1A

Voolutarve

4.9 Watts

Ergonoomika

Pöördenurga ulatus

355 °

Logistika andmed

Kogus transpordikasti kohta

1

Muud funktsioonid

Toetatud resolutsioonid

1280 x 720 (HD 720)/1280 x 960/1920 x 1080 (HD 1080)/2304 x 1296/2560 x 1440

Töötingimused

Hoiustamistemperatuur (T-T)

-40 - 60 °C

Kasutamistemperatuur (T-T)

-40 - 60 °C

Suhteline õhuniiskus kasutamisel (H-H)

0 - 95 %

.: Pakendi andmed :.

Max kogus transpordipakendis

1

Pakendi maht

0.002537 cubm

Transpordipakendi kaal

0.639 kg

Transpordipakendi kõrgus

14.5 cm

Transpordipakendi laius

12.5 cm

Transpordipakendi sügavus

14 cm

Pakendi kaal

592 g

Tehnilised andmed

Placement supported

Indoor & outdoor

Number of cameras

1

Wide Dynamic Range (WDR)

Jah

Number of illumination LEDs

3

LED type

IR

Audio codecs

G.711a; G.711Mu; PCM; G.726; G.723

Remote viewing

Jah

Detection Distance

80 m

Unit Box Height

0.145

Unit Box Length

0.14

Unit Box Width

0.125

CnKood

85258900

Üksuse kalkuleeritud maht

0.002537 cubm

Tilt angle range

0 - 75 °

Adjustment shutter speed

Automaatne/Manuaalne

IK code

IK10

Back Light Compensation (BLC)

Jah

Digital Wide Dynamic Range (DWDR)

Jah

Highlight Compensation (HLC)

Jah

Noise reduction technology

3D noise reduction

Smart IR

Jah

Mirror

Jah

Digital Wide Dynamic Range (DWDR) (panoramic camera)

Jah

Number of sensors

1

Number of lenses

1

Intelligent Video Surveillance (IVS) system features

Intrusion

Detect distance

68 m

Identify distance

6.8 m

Observe distance

27.2 m

Recognize distance

13.6 m

Bit rate control

Constant Bit Rate (CBR)/Variable Bit Rate (VBR)

Fixed focal length (thermal module)

2.8 mm

Video intelligence analytic

Jah

Audio system full duplex

Jah

Rahvusvaheline Kaitsekood ( IP )

IP67

Camera shutter type

Elektrooniline

Day/night mode

Jah

DC output voltage

12

Ethernet interface type

Kiire Ethernet

Ethernet LAN (RJ-45) ports

1

Maximum aperture number

2

Mobile operating systems supported

Android/iOS

Mounting type

Ceiling

Noise reduction

Jah

Sensor type

CMOS

Supported video modes

1080p/720p

Video compression formats

H.264+/H.264H/H.265+

Video formats supported

H.264/H.264B/H.265

Video recording

Jah

Audio system

1-way

Bit rate

3 Kbps - 20480 Kbps

Built-in HDD

Ei

Camera design

Dome

Camera shutter speed

1/3 - 1/100000 s

Certification

CE-LVD: EN62368-1;
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU;
CE-RED: Radio Equipment Directive 2014/53/EU;
FCC: 47 CFR FCC Part 15, Subpart B;
FCC ID: FCC PART 15C

Connectivity Technology

Juhtmega & juhtmevaba

Diameter

110.7 mm

Electronic Shutter Speed

Automaatne/manuaalne 1/3 s–1/100, 000 s

Environment

Välitingimustesse

Focal Length

2.8 mm

Frame Rate

30 fps

Housing material

Metall

IR Illumination

Jah

Lens Mount

M12

Maximum memory card size

256 GB

MicroSD Card Slot

1

Min. Illumination

0.025 Lux

Network Camera Type

Fixed Dome/HDTV/Megapixel/Outdoor

Night vision distance

30 m

Number of users

6 user(s)

Operating temperature range

-40°C to +50°C

Optical sensor size

1/3 "

Pan range

0 - 355 °

Pixel Resolution

4 Mega Pixel

Power Options

12V

Resolution

4 Mega Pixel

Sensor size

1/3” 4

Total megapixels

4 MP

Video streaming

Jah

Tehnilised andmed

Üksuse kalkuleeritud kaal

0.639 kg

Netokaal

0.414 kg

Brutokaal

0.639 kg

Kõrgus

88.7 mm

Toote kaal

414 g
