NET CAMERA 4MP IR DOME AI/IPC-HDBW3441R-AS-P-0210B DAHUA
E1
Vajad toodet suuremas koguses või püsitellimust?
Võta ühendust meie klienditoega info[at]digipood.eu
Kuumakse al. 15.40 €. Taotle järelmaksu ostukorvis.
Series Overview
With advanced deep learning algorithm, Dahua WizSense 3 Series
network camera supports intelligent functions, such as perimeter
protection and smart motion detection. With starlight technology, this
series camera provides a better image effect in the condition of low
illuminance.
Launched by Dahua Technology, WizSense is a series of AI products and
solutions that adopt independent AI chip and deep learning algorithm.
It focuses on human and vehicle with high accuracy, enabling users to
fast act on defined targets. Based on Dahua's advanced technologies,
WizSense provides intelligent, simple and inclusive products and
solutions.
Functions
EPTZ
With advanced target detection and tracking algorithms, Dahua EPTZ
technology can simultaneously zoom in and track multiple humans and
vehicles that trigger alarms. It provides rich details and a panoramic
view at the same time.
SMD 3.0
With intelligent algorithm, Dahua Smart Motion Detection technology
can categorize the targets that trigger motion detection and filter the
motion detection alarm triggered by non-concerned targets to realize
effective and accurate alarm.
Smart H.265+ & Smart H.264+
With advanced scene-adaptive rate control algorithm, Dahua smart
encoding technology realizes the higher encoding efficiency than H.265
and H.264, provides high-quality video, and reduces the cost of storage
and transmission.
Perimeter Protection
With deep learning algorithm, Dahua Perimeter Protection technology
can recognize human and vehicle accurately. In restricted area (such
as pedestrian area and vehicle area), the false alarms of intelligent
detection based on target type (such as tripwire, intrusion) are largely
reduced.
- 4-MP 1/2.7" CMOS starlight-grade image sensor, low luminance, and high definition image
- Outputs 4 MP (2688 × 1520) @25/30 fps, and supports max. 5 MP (2880 × 1620) @20 fps
- H.265 codec, high compression rate, ultra-low bit rate
- Built-in IR LED, and the max. illumination distance is 15 m
- ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments
- Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
- Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human)
- Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection
- Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; built in MIC
- 12 VDC/PoE power supply
- IP67, IK10 protection
- EPTZ: Enlarge and track the targets of intelligent alarms
- SMD 3.0
.: Üldised andmed :.
- Seadme tüüp
- IP security camera
- Tootja koduleht
- https://www.dahuasecurity.com/products/All-Products/Network-Cameras/WizSense-Series/3-Series/Wide-Angle/IPC-HDBW3441R-AS-P
.: Disain :.
- Toote värv
- Assorted colours
- Kujutegur
- Dome
- LED-indikaatorid
- Jah
.: Mälu :.
- Integreeritud kaardilugeja
- Jah
- Ühilduvad mälukaardid
- MicroSD (TransFlash)
- Paigaldatud operatiivmälu
- 512 MB
.: Audio :.
- Sisseehitatud mikrofon
- Built-in
.: Kaamera :.
- Lens viewing angle, vertical
- 75 °
- Valge tasakaalustus
- Auto/Custom modes/Manual/Natural/Outdoor/Street lamp
.: Võrgustumine :.
- Võrgustandardid
- IEEE 802.1x
- Web browser
- Jah
- WiFi
- Ei
- Ethernet LAN
- Jah
- Bluetooth
- Ei
.: Pesad & liidesed :.
- Audioväljund
- 1
- Ethernet LAN (RJ-45) pordid
- 1
.: Aku & Toiteallikas :.
- Toiteallika tüüp
- DC,PoE
Võimsus ja energiatarve
- Võimsustarve (tüüpiline)
- 3.2 W
.: Salvestusruum :.
- ROM capacity
- 128 MB
Pildisensor
- Progressiivne skaneerimine
- Jah
Juhtimisfunktsioonid
- Veebipõhine haldus
- Jah
Objektiivi süsteem
- Lens viewing angle, diagonal
- 175 °
- Lens viewing angle, horizontal
- 170 °
Öövaatluse funktsioon
- Öönägemine
- Jah
Toide
- Toitenõuded
- PoE / 12VDC power
- Voolutarve
- 7.7 Watts
Ergonoomika
- Pöördenurga ulatus
- 355 °
Logistika andmed
- Kogus transpordikasti kohta
- 1
Töötingimused
- Kasutamistemperatuur (T-T)
- -40 - 60 °C
- Suhteline õhuniiskus kasutamisel (H-H)
- 0 - 95 %
- Hoiustamistemperatuur (T-T)
- -40 - 60 °C
.: Pakendi andmed :.
- Max kogus transpordipakendis
- 1
- Pakendi maht
- 0.005776 cubm
- Transpordipakendi kaal
- 0.775 kg
- Transpordipakendi kõrgus
- 19 cm
- Transpordipakendi laius
- 16 cm
- Transpordipakendi sügavus
- 19 cm
- Pakendi kaal
- 770 g
Tehnilised andmed
- Placement supported
- Indoor & outdoor
- Supported network protocols
- IPv4; IPv6; HTTP;TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP
- Number of cameras
- 1
- Wide Dynamic Range (WDR)
- Jah
- Alarm input/output
- Jah
- Supports card capacities up to
- 256GB
- Unit Box Height
- 0.19
- Unit Box Length
- 0.19
- Unit Box Width
- 0.16
- CnCode
- 85258900
- Unit Calculated Volume
- 0.005776 cubm
- Unit Calculated Weight
- 0.775 kg
- Summary
- Dahua Technology WizSense DH-IPC-HDBW3441R-AS-P. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product colour: Assorted colours, Form factor: Dome. Minimum illumination: 0.0005 lx, Angle of rotation: 355°, Lens viewing angle, horizontal: 170°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.7 mm (1 / 2.7"), Number of effective pixels (H x V): 2880 x 1620 pixels. Fixed focal length: 2.1 mm, Closest focusing distance: 0.6 m
- Tilt angle range
- 0 - 80 °
- Adjustment shutter speed
- Auto/Manual
- Number of effective pixels (H x V)
- 2880 x 1620 pixels
- IK code
- IK10
- Camera tilt control
- Ei
- Back Light Compensation (BLC)
- Jah
- Highlight Compensation (HLC)
- Jah
- Noise reduction technology
- 3D noise reduction
- Number of sensors
- 1
- Number of lenses
- 1
- Behavior analysis
- Intrusion detection,Line crossing detection
- Region of Interest (ROI) encoding
- Jah
- Streaming method
- Multicast/Unicast
- Weatherproof
- Jah
- Dynamic range
- 120 dB
- Bit rate control
- Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
- Power consumption (Power over Ethernet (PoE))
- 7.7 W
- Gain control type
- Auto/Manual
- Fog proof
- Jah
- Camera shutter type
- Electronic
- Day/night mode
- Jah
- DC output voltage
- 12
- Ethernet LAN (RJ-45) ports
- 1
- Maximum aperture number
- 2
- Mobile operating systems supported
- Android/iOS
- Mounting type
- Ceiling/wall
- Noise reduction
- Jah
- Sensor type
- CMOS
- Video compression formats
- H.264/H.264B/H.265/M-JPEG
- Video formats supported
- H.264+/H.265+
- Alarm In
- 1
- Alarm Out
- 1
- Built-in HDD
- Ei
- Camera design
- Dome
- Camera shutter speed
- 1/3 s-1/100,000 s
- Closest focusing distance
- 0.6 m
- Connectivity Technology
- Wired
- Diameter
- 122 mm
- Environment
- Outdoor
- Fixed focal length
- 2.1 mm
- Focal Length
- 2.1 mm
- Housing material
- Metal
- IR Illumination
- Jah
- Lens Mount
- M12
- Maximum memory card size
- 256 GB
- MicroSD Card Slot
- 1
- Min. Illumination
- 0.001 Lux
- Minimum Illumination
- 0.0005 lx
- Network Camera Type
- Fixed Dome/Outdoor
- Number of users
- 20 user(s)
- Operating temperature range
- -40°C~+60°C
- Optical sensor size
- 1/2.7 "
- Pan range
- 0 - 355 °
- Pixel Resolution
- 4 Mega Pixel
- Power Options
- 12V/PoE
- Resolution
- 4 Mega Pixel
- Sensor size
- 1/2.7" CMOS
- Total megapixels
- 4 MP
Tehnilised andmed
- Netokaal
- 0.5 kg
- Netokaal
- 0.5 kg
- Brutokaal
- 0.775 kg
- Kõrgus
- 94 mm
- Mõõtmed (l x s x k)
- 94 mm × Φ122.0 mm
- Toote kaal
- 500 g
