Mainboard|GIGABYTE|Intel H610|LGA1700|Micro-ATX|Memory DDR4|Memory slots 2|1xPCI-Express 3.0 1x|1xPCI-Express 4.0 16x|1xM.2|1x15pin D-sub|1xHDMI|4xUSB 2.0|2xUSB 3.2|1xPS/2|1xRJ45|3xAudio port|H610MHV3DDR4

Muud näitajad

PCI Express x16 slots

1

Compatible processor series

Intel® Celeron®/Intel® Core™ i3/Intel® Core™ i5/Intel® Core™ i7/Intel® Core™ i9/Intel® Pentium® Gold

Supported processor sockets

LGA 1700

BIOS type

UEFI AMI

ATX Power connector (24-pin)

Jah

EPS power connector (8-pin)

Jah

Memory slots type

DIMM

Motherboard chipset family

Intel

Supported memory types

DDR4-SDRAM

Memory channels

Dual-channel

Front panel audio connector

Jah

CPU fan connector

Jah

Number of SATA III connectors

4

Parallel processing technology support

Ei ole toetatud

Clear CMOS jumper

Jah

Clear CMOS button

Jah

ACPI version

5.0

Number of M.2 (M) slots

1

Number of storage drives supported

5

Supported storage drive types

HDD & SSD

PCI Express x1 slots

1

Supported memory module capacities

12GB/16GB/1GB/2GB/32GB/4GB/8GB

Supported storage drive interfaces

M.2,SATA III

Processor manufacturer

Intel

Serial port headers

1

System management BIOS (SMBIOS) version

2.7

RGB LED pin header

Jah

USB 3.2

Jah

PCI-Express 4.0 16x

1

Supported memory clock speed (max)

3200 MHz

Unit Box Height

0.055

Unit Box Length

0.265

Unit Box Width

0.235

CnKood

84733020

Garantiiaeg

3 aasta(s)

ECC сompatibility

ECC & Non-ECC

Üksuse kalkuleeritud maht

0.004113 cubm

Üksuse kalkuleeritud kaal

0.753 kg

Kokkuvõte

GIGABYTE H610M H V3 DDR4 Motherboard - Supports Intel Core 14th CPUs, 4+1+1 Hybrid Phases Digital VRM, up to 3200MHz DDR4, 1xPCIe 3.0 M.2, GbE LAN, USB 3.2 Gen 1. Processor manufacturer: Intel, Processor socket: LGA 1700, Compatible processor series: Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9,.... Supported memory types: DDR4-SDRAM, Maximum internal memory: 64 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, SATA III, Supported storage drive types: HDD & SSD. Graphics card family: Intel, Graphics card: HD Graphics, Maximum resolution: 4096 x 2304 pixels. USB connector type: USB Type-A

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

2

Products per shipping (inner) case

1 tk

Audio chip

Realtek ALC897

Graphics card

HD graafika

Graphics card family

Intel

Number of HDDs supported

1

USB 3.2 Gen 1 (3.1 Gen 1) connectors

1

PC health monitoring

Fan/Temperature/Voltage/Water cooling

Desktop Management Interface (DMI) version

2.7

12V power connector

Jah

Front panel connector

Jah

Lithium weight per battery

0.07 g

Tootja koduleht

https://www.gigabyte.com/

Mudel

H610M H V3 DDR4

Pakendi laius

265 mm

Pakendi kõrgus

52 mm

Kaasas tarkvara

Norton Internet Security (OEM version)
LAN bandwidth management software

Component for

PC

Transpordipakendi kaal

7.53 kg

Transpordipakendi kõrgus

26 cm

Transpordipakendi laius

28 cm

Transpordipakendi sügavus

56.5 cm

Kogus transpordikasti kohta

10

Akuelementide arv

1

Akutehnoloogia

Lithium-Manganese Dioxide (LiMnO2)

Pakendi sügavus

235 mm

Maksimaalne resolutsioon

4096 x 2304 pixels

Pakendi kaal

684 g

HDCP

Jah

Kõrgus

35 mm

DisplayPorts quantity

2

DVI-D ports quantity

1

Ethernet interface type

Gigabit Ethernet

Ethernet LAN (RJ-45) ports

1

Jahutuse tüüp

Aktiivne

Headphone outputs

3

Päritoluriik

China

Toote värv

Must

Microphone in

Jah

Motherboard chipset

Intel H610 Express

Unbuffered memory

Jah

USB connector type

USB Type-A

VGA (D-Sub) ports quantity

1

Windows operating systems supported

Windows 10 x64/Windows 11 x64

Batteries Included

Jah

Battery type

CR2032

Battery weight

3 g

BIOS memory size

128 Mbit

Number of memory slots

2

Processor Socket

LGA 1700

Supported memory clock speeds

2133/2400/2666/2933/3000/3200 MHz

USB 2.0 connectors

2
