NET CAMERA 8+4MP PTZ DOME/SDT4E425-8P-GB-APV1 DAHUA

.: Üldised andmed :.

Tootja koduleht

https://www.dahuasecurity.com/products/All-Products/PTZ-Cameras/X-Spans-Series/Distribution/SDT4E425-8P-GB-APV1

Seadme tüüp

IP security camera

.: Disain :.

Kokkuvõte

Dahua Technology WizSense SDT4E425-8P-GB-APV1. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product colour: White, Form factor: Dome. Tilt preset speed: 90 °/sec, Tilt manual speed: 0.1 - 90 °/sec, Pan preset speed: 180 °/sec. Sensor type: CMOS. Digital zoom: 16x, Detect distance: 56 m, Observe distance: 24.4 m

Kujutegur

Dome

Toote värv

Valge

.: Võrgustumine :.

WiFi

Ei

Ethernet LAN

Jah

Bluetooth

Ei

.: Pesad & liidesed :.

Audioväljund

1

Ethernet LAN (RJ-45) pordid

1

.: Aku & Toiteallikas :.

Toiteallika tüüp

DC,PoE

Öövaatluse funktsioon

Öönägemine

Jah

Toide

Toitenõuded

12 VDC, 3 A ± 10%; PoE+ (802.3at)

Voolutarve

25 W

Logistika andmed

Kogus transpordikasti kohta

2

.: Pakendi andmed :.

Max kogus transpordipakendis

1

Pakendi maht

0.03058 cubm

Transpordipakendi kaal

4.73 kg

Transpordipakendi kõrgus

24 cm

Transpordipakendi laius

26 cm

Transpordipakendi sügavus

49 cm

Kasutusjuhend

Jah

Tehnilised andmed

Placement supported

Indoor & outdoor

Number of cameras

1

Wide Dynamic Range (WDR)

Jah

Alarm input/output

Jah

Built-in light

Jah

Video motion detection

Jah

Remote viewing

Jah

Supports card capacities up to

512GB

Unit Box Height

0.24

Unit Box Length

0.49

Unit Box Width

0.26

CnKood

85258900

Üksuse kalkuleeritud maht

0.03863 cubm

Camera pan control

Jah

Camera tilt control

Jah

Back Light Compensation (BLC)

Jah

Highlight Compensation (HLC)

Jah

Noise reduction technology

2D noise reduction,3D noise reduction

Mirror

Jah

Region of Interest (ROI) encoding

Jah

Detect distance

56 m

Observe distance

24.4 m

Recognize distance

11.2 m

Bit rate control

Constant Bit Rate (CBR),Variable Bit Rate (VBR)

Alarm input channels

2

Alarm output channels

1

Gain control type

Automaatne/Manuaalne

PTZ control

Jah

PTZ modes

Preset point

Pan manual speed

0.1 - 180 °/sec

Pan preset speed

180 °/sec

Tilt manual speed

0.1 - 90 °/sec

Tilt preset speed

90 °/sec

Detect distance (tele)

2500 m

Detect distance (wide)

100 m

Identify distance (tele)

250 m

Identify distance (wide)

10 m

Observe distance (tele)

1000 m

Observe distance (wide)

40 m

Recognize distance (tele)

500 m

Recognize distance (wide)

20 m

Preset points

Jah

Tour recording

Jah

Rahvusvaheline Kaitsekood ( IP )

IP66

Audio sisend

1

Camera shutter type

Elektrooniline

Day/night mode

Jah

DC output voltage

12

Ethernet LAN (RJ-45) ports

1

Mounting type

Ceiling/wall

Noise reduction

Jah

Sensor type

CMOS

Alarm In

2

Alarm Out

1

Bit rate

H265: 51 kbps-13,312 kbps

Built-in HDD

Ei

Built-in microphone

Jah

Camera design

PT/PTZ

Camera shutter speed

1 - 1/30000 s

Connectivity Technology

Juhtmega

Digital Zoom

16 x

Environment

Välitingimustesse

Frame Rate

30 fps

IR Illumination

Jah

Min. Illumination

0.0005 Lux

Network Camera Type

Fixed Dome/HDTV/Megapixel/PTZ

Operating temperature range

–40 °C to +65 °C

Power Options

12V/PoE

Sensor size

1/2.8"

Signal-to-Noise Ratio (SNR)

55 dB

Total megapixels

8 MP

Tehnilised andmed

Üksuse kalkuleeritud kaal

5.25 kg

Netokaal

3.41 kg

Brutokaal

4.73 kg

Laius

194.2 mm

Sügavus

160 mm

Kõrgus

311 mm

Mõõtmed (l x s x k)

160.0 × 184.4 × 304.6mm

Toote kaal

3100 g
