The SWM282 is a high-capacity L2 managed switch with enhanced L3 capabilities, built to simplify network control while delivering power and connectivity at scale. It features 24 PoE+ ports, supplying up to 30 W per port with a total power budget of 300 W, and 4 SFP ports. With support for PROFINET and other industrial protocols, this 24-port switch is an ideal choice for enterprise networks and IIoT solutions.
| Tootja | Teltonika |
| Tootekood | SWM282 |
| EAN | 4779051846276 |
| Google link | lisainfo |
| Garantiiaeg | 24 kuud |
| .: Üldised andmed :. | |
| Tootja koduleht | https://www.teltonika-networks.com/products/ethernet-switches/swm282 |
| .: Üldised omadused :. | |
| Välkmälu | 16 MB |
| .: Disain :. | |
| Toote värv | Black |
| .: Protsessor :. | |
| Protsessori sagedus | 500 MHz |
| Sisseehitatud protsessor | Jah |
| .: Mälu :. | |
| Paigaldatud operatiivmälu | 128 MB |
| .: Võrgustumine :. | |
| Võrgustandardid | IEEE 802.1p/IEEE 802.1Q/IEEE 802.1x/IEEE 802.3ab/IEEE 802.3af/IEEE 802.3at/IEEE 802.3az/IEEE 802.3i/IEEE 802.3u/IEEE 802.3x |
| VLAN-i tugi | Jah |
| Auto MDI/MDI-X | Jah |
| Ethernet LAN-i andmeedastuskiirused | 10,100,1000 Mbit/s |
| Võimsus ja energiatarve | |
| Power over Ethernet (PoE) | Jah |
| Sisendsagedus | 50/60 Hz |
| Turvalisus | |
| DHCP features | DHCP client/DHCP server/DHCPv6 client |
| Queue scheduling algorithms | SP/Weighted Round Robin (WRR)/WFQ |
| .: Tehnilised andmed :. | |
| Compliance certificates | CB/CE/Federal Communications Commission (FCC)/Industry Canada (IC)/RCM/UKCA |
| Sisemälu tüüp | DDR3-SDRAM |
| Andmeedastus | |
| Static route | Jah |
| Jumbo frames | 10000 |
| Juhtimisfunktsioonid | |
| Teenusekvaliteedi (QoS) tugi | Jah |
| Veebipõhine haldus | Jah |
| Ergonoomika | |
| Lähtestusnupp | Jah |
| Funktsioonid | |
| Uuendatav tarkvara | Jah |
| Vahelduvvoolu pinge | 100 - 240 V |
| Mudeli originaalnimi | SWM282000200 |
| Internet elektrivõrgu kaudu (PoE) | |
| Power over Ethernet (PoE) type supported | Active PoE/PoE+ |
| Logistika andmed | |
| Kogus transpordikasti kohta | 1 |
| Töötingimused | |
| Kasutamistemperatuur (T-T) | 0 - 50 °C |
| Suhteline õhuniiskus kasutamisel (H-H) | 10 - 90 % |
| .: Pakendi sisu :. | |
| Kiirpaigaldusjuhend | Jah |
| .: Pakendi andmed :. | |
| Pakendi tüüp | Box |
| Power over Ethernet (PoE) modes | Alternative A |
| Rack mounting | Jah |
| MAC address filtering | Jah |
| Switch layer | L2+ |
| Jumbo frames support | Jah |
| Port mirroring | Jah |
| 10G support | Ei |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| SFP module slots quantity | 4 |
| Power over Ethernet plus (PoE+) ports quantity | 24 |
| Rate limiting | Jah |
| Unit Box Height | 0.1 |
| Authentication type | RADIUS,TACACS+ |
| Loop protection | Jah |
| Traffic shaping | Jah |
| Summary | Teltonika SWM282. Switch type: Managed, Switch layer: L2+. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24. MAC address table: 8000 entries, Switching capacity: 56 Gbit/s. Networking standards: IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az, IEEE 802.1x, IEEE 802.3af, IEEE.... Power connector: AC-in jack. Power over Ethernet (PoE). Rack mounting |
| Unit Calculated Weight | 2.58 kg |
| Unit Calculated Volume | 0.01716 cubm |
| Unit Box Width | 0.33 |
| Unit Box Length | 0.52 |
| Power supply included | Ei |
| Forwarding rate | 83.33 Mpps |
| Housing material | Aluminium |
| MAC address table | 8000 entries |
| Packet buffer memory | 0.512 MB |
| Power Connector | AC-in jack |
| Power over Ethernet (PoE) power per port | 30 W |
| Power Source | AC |
| Switch type | Managed |
| Switching capacity | 56 Gbit/s |
| Total Power over Ethernet (PoE) budget | 300 W |
| Laius | 483 mm |
| Sügavus | 234 mm |
| Kõrgus | 44 mm |
| Toote kaal | 2291 g |
