NET CAMERA 5MP IR EYEBALL/IPC-HDW5541T-ZE-27135-S3 DAHUA
E1
Vajad toodet suuremas koguses või püsitellimust?
Võta ühendust meie klienditoega info[at]digipood.eu
Kuumakse al. 17.45 €. Taotle järelmaksu ostukorvis.
Launched by Dahua Technology, Dahua WizMind is a full portfolio of solutions composed of project-oriented products including IPC, IVSS,NVR, PTZ, XVR, Thermal and software platform which adopts
industry-leading deep learning algorithms. Focusing on customer's requirements, WizMind provides precise, reliable and comprehensive AI solutions for verticals.
Driven by deep learning algorithms, Dahua WizMind S Series network camera offers a variety of intelligent functions that greatly improve the accuracy of audio and video analysis. It supports video metadata,
smart sound detection, face detection, perimeter protection, people counting and more. The camera also adopts advanced image processing AI ISP technology and has the Deeplight night vision effect. The camera
is dustproof, waterproof and vandal-proof, and is certified as IP67 and IK10 (the type of protection varies depending on the model).
- 5-MP 1/2.7" CMOS image sensor, low luminance, and high definition image
- Outputs max. 5MP (2960×1668) @25/30 fps
- Built-in IR LED, and the max. illumination distance is 40 m
- ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments
- Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
- With deep learning algorithm, it supports: video metadata, IVS, face detection, smart object detection, and people counting, etc
- Supports max. 1 TB Micro SD card, built-in MIC
- 12 VDC/PoE power supply; ePoE
- IP67 protection
- SMD 3.0
.: Üldised andmed :.
- Seadme tüüp
- CCTV security camera
- Tootja koduleht
- https://www.dahuasecurity.com/products/All-Products/Network-Cameras/WizMind-5-Series/S-Series/5MP/IPC-HDW5541T-ZE=S3
.: Disain :.
- Toote värv
- White
- Kujutegur
- Turret
- Toote värv
- White
.: Mälu :.
- RAM capacity
- 1000 MB
- Integreeritud kaardilugeja
- Jah
- Ühilduvad mälukaardid
- MicroSD (TransFlash)
.: Audio :.
- Sisseehitatud mikrofon
- Built-in
.: Kaamera :.
- Lens viewing angle, vertical
- 58-17 °
- Valge tasakaalustus
- Auto/Manual/Natural/Outdoor/Regional custom/Street lamp
.: Võrgustumine :.
- WiFi
- Ei
- Ethernet LAN
- Jah
- Bluetooth
- Ei
.: Pesad & liidesed :.
- Ethernet LAN (RJ-45) pordid
- 1
.: Aku & Toiteallikas :.
- Toiteallika tüüp
- DC,PoE
Võimsus ja energiatarve
- Võimsustarve (tüüpiline)
- 3.7 W
.: Salvestusruum :.
- ROM capacity
- 4000 MB
Pildisensor
- Progressiivne skaneerimine
- Jah
Objektiivi süsteem
- Lens viewing angle, diagonal
- 138-36 °
- Lens viewing angle, horizontal
- 114-32 °
Öövaatluse funktsioon
- Öönägemine
- Jah
Toide
- Toitenõuded
- 12 VDC/PoE (802.3af)/ePoE
- Voolutarve
- 4.8 Watts
Ergonoomika
- Pöördenurga ulatus
- 360 °
Logistika andmed
- Kogus transpordikasti kohta
- 1
Töötingimused
- Kasutamistemperatuur (T-T)
- -30 - 60 °C
- Suhteline õhuniiskus kasutamisel (H-H)
- -40 - 60 %
- Hoiustamistemperatuur (T-T)
- 0 - 95 °C
.: Pakendi andmed :.
- Max kogus transpordipakendis
- 1
- Pakendi maht
- 0.00331 cubm
- Transpordipakendi kaal
- 0.94 kg
- Transpordipakendi kõrgus
- 13.6 cm
- Transpordipakendi laius
- 15.7 cm
- Transpordipakendi sügavus
- 15.5 cm
- Pakendi kaal
- 960 g
Tehnilised andmed
- Placement supported
- Indoor & outdoor
- Supported network protocols
- IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; P2P; Auto Register
- Number of cameras
- 1
- Wide Dynamic Range (WDR)
- Jah
- Video motion detection
- Jah
- Number of illumination LEDs
- 2
- LED type
- IR
- Supports card capacities up to
- 1TB
- Unit Box Height
- 0.136
- Unit Box Length
- 0.155
- Unit Box Width
- 0.157
- CnCode
- 85258900
- Unit Calculated Volume
- 0.00331 cubm
- Unit Calculated Weight
- 0.94 kg
- Summary
- Dahua Technology WizMind IPC-HDW5541T-ZE. Type: CCTV security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Ceiling, Product colour: White, Form factor: Turret. Minimum illumination: 0.0005 lx, Angle of rotation: 360°, Lens viewing angle, horizontal: 114-32°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.7 mm (1 / 2.7"), Number of effective pixels (H x V): 2960 x 1668 pixels. Detect distance: 210 m, Observe distance: 84 m, Recognize distance: 42 m
- Tilt angle range
- 0 - 78 °
- Number of effective pixels (H x V)
- 2960 x 1668 pixels
- Back Light Compensation (BLC)
- Jah
- Highlight Compensation (HLC)
- Jah
- Noise reduction technology
- 3D noise reduction
- Mirror
- Jah
- Region of Interest (ROI) encoding
- Jah
- Detect distance
- 210 m
- Focal length range
- 2.7 - 13.5 mm
- Identify distance
- 21 m
- Observe distance
- 84 m
- Recognize distance
- 42 m
- Number of Privacy masking areas
- 8
- Bit rate range
- 12 - 16384 Kbit/s
- Power consumption (Power over Ethernet (PoE))
- 4.8 W
- Flip & mirror
- Jah
- Gain control type
- Auto
- People counting function
- Jah
- Digital watermark
- Jah
- Camera shutter type
- Electronic
- Day/night mode
- Jah
- DC output voltage
- 12
- Ethernet interface type
- Fast Ethernet
- Ethernet LAN (RJ-45) ports
- 1
- Maximum aperture number
- 1.5
- Mounting type
- Ceiling
- Noise reduction
- Jah
- Sensor type
- CMOS
- Video compression formats
- H.264/H.264+/H.264B/H.264H/H.265/H.265+/M-JPEG
- Video recording
- Jah
- Built-in HDD
- Ei
- Built-in microphone
- Jah
- Camera design
- Eyeball
- Camera shutter speed
- 1/3 - 1/100000 s
- Closest focusing distance
- 0.8 m
- Connectivity Technology
- Wired
- Diameter
- 122 mm
- Effective pixels
- 2960 (H) × 1668 (V)
- Electronic Shutter Speed
- Auto/Manual 1/3 s–1/100,000 s
- Focal Length
- 2.7 mm–13.5 mm
- Housing material
- Metal
- Image stabilizer
- Jah
- IR Illumination
- Jah
- Maximum memory card size
- 1000 GB
- Min. Illumination
- 0.0005 Lux
- Minimum Illumination
- 0.0005 lx
- Network Camera Type
- HDTV/Megapixel
- Night vision distance
- 40 m
- Number of users
- 20 user(s)
- Operating temperature range
- –30 °C to +60 °C
- Optical sensor size
- 1/2.7 "
- Pan range
- 0 - 360 °
- Pixel Resolution
- 5 Mega Pixel
- Resolution
- 5 Mega Pixel
- Sensor size
- 1/2.7" CMOS
- Signal-to-Noise Ratio (SNR)
- 56 dB
- Storage relative humidity (H-H)
- 10 - 95 %
- Total megapixels
- 5 MP
Tehnilised andmed
- Netokaal
- 0.7 kg
- Netokaal
- 0.7 kg
- Brutokaal
- 0.94 kg
- Kõrgus
- 108.3 mm
- Mõõtmed (l x s x k)
- Φ122.0 mm × 108.3 mm
- Toote kaal
- 700 g
