UPS|EATON|920 Watts|230 VA|Wave form type Sinewave|LineInteractive|Rack 1U|5P1150IRG2

.: Üldised andmed :.

Tootja koduleht

https://www.eaton.com/ua/en-gb/skuPage.5P1150IRG2.html

.: Üldised omadused :.

Müratase

35 dB

.: Disain :.

Toote värv

Black,Silver

Kujutegur

Tower

Toote värv

Black / Silver

.: Pesad & liidesed :.

USB port

Jah

.: Aku & Toiteallikas :.

Akutehnoloogia

Sealed Lead Acid (VRLA)

Aku mahutavus

9 Ah

Võimsus ja energiatarve

Output frequency

50/60 Hz

Väljundvõimsus

920 W

Logistika andmed

Kogus transpordikasti kohta

1

Töötingimused

Kasutamistemperatuur (T-T)

0 - 40 °C

Suhteline õhuniiskus kasutamisel (H-H)

0 - 90 %

.: Pakendi sisu :.

Kiirpaigaldusjuhend

Jah

.: Pakendi andmed :.

Kasutusjuhend

Jah

Max kogus transpordipakendis

1

Pakendi maht

0.058941 cubm

Transpordipakendi kaal

19.2 kg

Transpordipakendi kõrgus

18.5 cm

Transpordipakendi laius

54 cm

Transpordipakendi sügavus

59 cm

Tehnilised andmed

Serial interface

Jah

Serial interface type

RS-232

Input operation voltage (min)

150 V

AC outlet types

C13 coupler

AC outlets quantity

6 AC outlet(s)

Waveform

Sine

Automatic Voltage Regulation (AVR)

Jah

Power plug

C14 coupler

Rack capacity

1U

Unit Box Height

0.185

Unit Box Length

0.59

Unit Box Width

0.54

CnCode

85044095

Unit Calculated Volume

0.058941 cubm

Product Net Weight

14.9 kg

Unit Calculated Weight

19.2 kg

Summary

Eaton 5P1150IRG2. UPS topology: Line-Interactive, Output power: 920 W, Waveform: Sine. AC outlet types: C13 coupler, Power plug: C14 coupler, AC outlets quantity: 6 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery capacity: 9 Ah, Battery voltage: 6 V. Form factor: Tower, Product colour: Black, Silver, Rack capacity: 1U. Certification: IEC/EN 62040-1 IEC/EN 62040-2 IEC/EN 62040-3 UL 1778 CSA-C22.2 CE UKCA Cm Ukr KCC cTUVus BIS

Number of input phases

1

Number of output phases

1

USB port type

USB Type-B

Number of batteries supported

4

Serial ports quantity

1

UPS topology

Line-Interactive

Battery voltage

6 V

Certification

IEC/EN 62040-1 IEC/EN 62040-2 IEC/EN 62040-3 UL 1778 CSA-C22.2 CE UKCA Cm Ukr KCC cTUVus BIS

Efficiency

98.2 %

Heat dissipation

465 BTU/h

Input frequency

50/60 Hz

Input operation voltage (max)

294 V

Input ports

Single, IEC320 C14

Operating altitude

0 - 3000 m

Output operation voltage (max)

240 V

Output power capacity, VA

230 VA

Output power capacity, W

920 Watts

Output power connector type

IEC 320 C13

Rack 1U

Jah

RS232

1

Topology

LineInteractive

USB

1

Wave form type

Sinewave

Tehnilised andmed

Netokaal

14.9 kg

Brutokaal

19.2 kg

Laius

438 mm

Sügavus

509 mm

Kõrgus

43.2 mm

Toote kaal

14200 g
