TSW202 is the first-ever managed industrial switch from Teltonika Networks, giving you greater control over how data flows through your network and the role its ports perform in your solution. Define their settings, routing, port mirroring, and more with simplicity and ease.
PoE+ with 30 W max power per port and 240 W total PSE makes the TSW202 centralize your power supply. PoE Management gives you more control over the power distribution of your solution, letting you turn PoE on or off on selected ports.
The switch is equipped with 8 Gigabit Ethernet VLAN ports, allowing for management, configuration, and monitoring of your network. Additional software features like QoS enhance effective bandwidth management and network traffic classifying and prioritizing.
Designed for industrial environments, the TSW202 features an integrated DIN rail bracket, rugged aluminum housing, and extreme temperature and vibration resistance for maximum durability with ease of installation.
| Tootja | Teltonika |
| Tootekood | TSW202 |
| EAN | 4779051840281 |
| Google link | lisainfo |
| Garantiiaeg | 24 kuud |
| .: Üldised andmed :. | |
| Tootja koduleht | teltonika-networks.com/products/ethernet-switches/tsw202 |
| .: Disain :. | |
| Toote värv | Aluminium/Blue |
| .: Võrgustumine :. | |
| VLAN-i tugi | Jah |
| .: Pesad & liidesed :. | |
| Ethernet LAN (RJ-45) pordid | 8 |
| Võimsus ja energiatarve | |
| Power over Ethernet (PoE) | Jah |
| Turvalisus | |
| DHCP features | DHCP client |
| Andmeedastus | |
| Jumbo frames | 10000 |
| Juhtimisfunktsioonid | |
| Veebipõhine haldus | Jah |
| Ergonoomika | |
| Lähtestusnupp | Jah |
| Funktsioonid | |
| Mudeli originaalnimi | TSW202000000 |
| Internet elektrivõrgu kaudu (PoE) | |
| Power over Ethernet (PoE) type supported | Active PoE |
| Logistika andmed | |
| Kogus transpordikasti kohta | 1 |
| Töötingimused | |
| Kasutamistemperatuur (T-T) | -40 - 75 °C |
| .: Pakendi andmed :. | |
| Max kogus transpordipakendis | 1 |
| Pakendi maht | 0.0009112 cubm |
| Transpordipakendi kaal | 0.64 kg |
| Transpordipakendi kõrgus | 13.5 cm |
| Transpordipakendi laius | 5 cm |
| Transpordipakendi sügavus | 13.5 cm |
| Gigabit Ethernet (copper) ports quantity | 8 |
| Full duplex | Jah |
| Switch layer | L2 |
| Jumbo frames support | Jah |
| Port mirroring | Jah |
| IGMP snooping | Jah |
| 10G support | Ei |
| Networking standards | IEEE 802.1p/IEEE 802.3af/IEEE 802.3at/IEEE 802.3z |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Power over Ethernet (PoE) ports quantity | 8 |
| Link aggregation | Jah |
| PoE power budget | 240 Watts |
| Unit Box Height | 0.135 |
| Unit Box Length | 0.135 |
| Unit Box Width | 0.05 |
| Unit Calculated Volume | 0.0009112 cubm |
| Product Net Weight | 0.5 kg |
| Unit Calculated Weight | 0.64 kg |
| Summary | Teltonika TSW202. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8, Installed SFP modules quantity: 2. Full duplex. MAC address table: 8000 entries, Switching capacity: 20 Gbit/s. Networking standards: IEEE 802.1p, IEEE 802.3af, IEEE 802.3at, IEEE 802.3z. Power connector: Terminal block (3-pin). Power over Ethernet (PoE) |
| Quality of Service (QoS) support | Jah |
| Rack mounting | Ei |
| Installed SFP modules quantity | 2 |
| DIN rail mounting | Jah |
| Active link detection | Jah |
| LED indicators | Power/Status |
| Power supply included | Ei |
| Auto-negotiation | Jah |
| Forwarding rate | 14.88 Mpps |
| Housing material | Aluminium |
| MAC address table | 8000 entries |
| PoE+ ports | 8 |
| Power Connector | Terminal block (3-pin) |
| Power over Ethernet (PoE) power per port | 30 W |
| Primary port count | 8 |
| SFP | 2 |
| Stackable | Ei |
| Switch type | Managed |
| Switching capacity | 20 Gbit/s |
| Total Power over Ethernet (PoE) budget | 240 W |
| Netokaal | 0.5 kg |
| Brutokaal | 0.64 kg |
| Laius | 132 mm |
| Sügavus | 44.2 mm |
| Kõrgus | 122 mm |
| Mõõtmed (l x s x k) | 132 x 44.2 x 122.2 mm |
| Toote kaal | 610 g |
