Switch|DAHUA|DH-CS4010-8ET2GT-60|Switch layer L2|8xRJ-45 ports|RJ-45 Ports Type Fast Ethernet (10/100)|2xGigabit Ethernet (copper) ports quantity|8xPower over Ethernet (PoE) ports quantity|Total Power over Ethernet (PoE) budget 60 W|CS4010-8ET2GT-60
46.60€
E1
E1
Vajad toodet suuremas koguses või püsitellimust?
Võta ühendust meie klienditoega info[at]digipood.eu
- 8 × RJ-45 10/100 Mbps PoE ports, 2 x RJ-45 Gigabit ports
- 60 W total PoE budget, 802.3af/at on all PoE ports, additional Hi-PoE on orange port
- DIP switch to fast turn on/off working mode of Cloud-Managed, PoE Watchdog, Long Distance PoE
- Wide operating temperature ranging from –10 °C to 55 °C
- Supports VLAN and loop protection
- WEB-managed and centralized cloud management through the DoLynk App and performs real-time monitoring of the network
- Easy config to auto detect and set up network and security systems
.: Üldised andmed :.
- Tootja koduleht
- https://transmission.dahuasecurity.com/en/product-list/business/cloudmanagementsolution/networkswitch/cs4010-8et2gt-60
.: Disain :.
- Toote värv
- Blue
- LED-indikaatorid
- Jah
.: Võrgustumine :.
- Võrgustandardid
- IEEE 802.1Q/IEEE 802.3/IEEE 802.3ab/IEEE 802.3af/IEEE 802.3at/IEEE 802.3az/IEEE 802.3u/IEEE 802.3x
- VLAN-i tugi
- Jah
- Ethernet LAN-i andmeedastuskiirused
- 10,100,1000 Mbit/s
Võimsus ja energiatarve
- Sisendvool
- 1.22 A
- Power over Ethernet (PoE)
- Jah
Turvalisus
- DHCP features
- DHCP client
.: Tehnilised andmed :.
- Compliance certificates
- CE
Andmeedastus
- Jumbo frames
- 9216
Juhtimisfunktsioonid
- Veebipõhine haldus
- Jah
Ethernet LAN-funktsioonid
- PoE ports
- 8
Ergonoomika
- Lähtestusnupp
- Jah
Funktsioonid
- Mudeli originaalnimi
- CS4010-8ET2GT-60
Logistika andmed
- Kogus transpordikasti kohta
- 20
Töötingimused
- Kasutamistemperatuur (T-T)
- -10 - 55 °C
- Suhteline õhuniiskus kasutamisel (H-H)
- 10 - 90 %
- Hoiustamistemperatuur (T-T)
- -40 - 70 °C
.: Pakendi andmed :.
- Kasutusjuhend
- Jah
- Kaablid kaasa arvatud
- AC
Tehnilised andmed
- Basic switching RJ-45 Ethernet ports quantity
- 10
- Number of VLANs
- 32
- Multicast support
- Jah
- Fast Ethernet (copper) ports quantity
- 8
- DC input voltage
- 53 V
- Flow control support
- Jah
- Power over Ethernet (PoE) ports quantity
- 8
- Basic switching RJ-45 Ethernet ports type
- Gigabit Ethernet (10/100/1000)
- PoE power budget
- 60 Watts
- 10G support
- Ei
- Broadcast storm control
- Jah
- Port mirroring
- Jah
- Jumbo frames support
- Jah
- Switch layer
- L2
- Gigabit Ethernet (copper) ports quantity
- 2
- Wall mountable
- Jah
- Rack mounting
- Ei
- Product Net Weight
- 0.36 kg
- IP-MAC-Port binding
- Jah
- Loop protection
- Jah
- Cloud-managed
- Jah
- Summary
- Dahua Technology CS4010-8ET2GT-60. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 10. MAC address table: 8000 entries, Switching capacity: 5.6 Gbit/s. Networking standards: IEEE 802.3af, IEEE 802.3at, IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, IEEE 802.3az, IEEE.... DC input voltage: 53 V. Power connector: DC-in jack. Power over Ethernet (PoE). Wall mountable
- Unit Calculated Weight
- 1 kg
- Unit Box Height
- 0.11
- Unit Calculated Volume
- 0.004615 cubm
- CnCode
- 85176200
- Unit Box Width
- 0.135
- Unit Box Length
- 0.25
- Power supply included
- Jah
- 10Base-T / 100Base-TX
- 8
- 10Base-T / 100Base-TX / 1000Base-T
- 2
- Forwarding rate
- 4.17 Mpps
- Housing material
- Metal
- MAC address table
- 8000 entries
- Mean time between failures (MTBF)
- 2837361 h
- Operating temperature range
- -10 °C ... 55 °C
- Package depth
- 252 mm
- Package height
- 113 mm
- Package weight
- 920 g
- Package width
- 137 mm
- Packet buffer memory
- 4 MB
- Power Connector
- DC-in jack
- Power Source
- DC/PoE
- Primary port count
- 10
- Storage relative humidity (H-H)
- 5 - 95 %
- Switch type
- Managed
- Switching capacity
- 5.6 Gbit/s
- Total Power over Ethernet (PoE) budget
- 60 W
Tehnilised andmed
- Laius
- 103.3 mm
- Sügavus
- 184.6 mm
- Kõrgus
- 27 mm
- Mõõtmed (l x s x k)
- 184.6 x 103.3 x 27.0 mm
- Toote kaal
- 360 g
