Switch|DAHUA|DH-SG4010P|Switch layer L2|10xRJ-45 ports|RJ-45 Ports Type Gigabit Ethernet (10/100/1000)|8xPower over Ethernet (PoE) ports quantity|Total Power over Ethernet (PoE) budget 110 W|SG4010P

.: Üldised andmed :.

Tootja koduleht

https://transmission.dahuasecurity.com/fr/product-list/Business/Switches/PoESwitchesForIT/SG4010P

.: Disain :.

Kokkuvõte

Dahua Technology SG4010P. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 2. MAC address table: 8000 entries, Switching capacity: 20 Gbit/s. Networking standards: IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, IEEE.... DC input voltage: 54 V. Power over Ethernet (PoE)

Toote värv

Must

.: Võrgustumine :.

Võrgustandardid

IEEE 802.3/IEEE 802.3ab/IEEE 802.3ad/IEEE 802.3af/IEEE 802.3at/IEEE 802.3az/IEEE 802.3bt/IEEE 802.3u/IEEE 802.3x/IEEE 802.3z

Ethernet LAN-i andmeedastuskiirused

10,100,1000 Mbit/s

VLAN-i tugi

Jah

Võimsus ja energiatarve

Sisendvool

2.22 A

Power over Ethernet (PoE)

Jah

Turvalisus

DHCP features

DHCP client

.: Tehnilised andmed :.

Vastavussertifikaadid

CE

Andmeedastus

Jumbo frames

15

Juhtimisfunktsioonid

Veebipõhine haldus

Jah

Toide

Toiteallikas

Alalisvool

Ethernet LAN-funktsioonid

IEEE 802.3

Jah

IEEE 802.3ab

Jah

IEEE 802.3u

Jah

IEEE 802.3x

Jah

PoE ports

8

Funktsioonid

Virtual LAN features

Port-based VLAN

Mudeli originaalnimi

DH-SG4010P

Logistika andmed

Kogus transpordikasti kohta

10

Töötingimused

Hoiustamistemperatuur (T-T)

-40 - 70 °C

Kasutamistemperatuur (T-T)

-10 - 55 °C

Suhteline õhuniiskus kasutamisel (H-H)

5 - 95 %

.: Pakendi andmed :.

Pakendi laius

256 mm

Pakendi kõrgus

87 mm

Kaablid kaasa arvatud

Alalisvool

Pakendi sügavus

244 mm

Pakendi kaal

1300 g

Tehnilised andmed

Basic switching RJ-45 Ethernet ports quantity

2

Flow control support

Jah

DC input voltage

54 V

Power over Ethernet (PoE) ports quantity

8

Number of VLANs

32

Link aggregation

Jah

PoE power budget

110 W

Unit Box Height

0.09

Unit Box Length

0.26

Unit Box Width

0.245

CnKood

85176200

Basic switching RJ-45 Ethernet ports type

Gigabit Ethernet (10/100/1000)

Broadcast storm control

Jah

Cloud-managed

Jah

Loop protection

Jah

Üksuse kalkuleeritud maht

0.006477 cubm

Jumbo frames support

Jah

IP-MAC-Port binding

Jah

Switch layer

L2

Power protection features

Over current/Over voltage

Power supply included

Jah

10Base-T / 100Base-TX / 1000Base-T

10

Desktop/pedestal

Jah

Forwarding rate

14.88 Mpps

Housing material

Metall

MAC address table

8000 entries

Mean time between failures (MTBF)

1115911.8 h

Operating temperature range

–10 °C to +55 °C

Packet buffer memory

4 MB

Power Options

PoE

Power over Ethernet (PoE) power per port

30 W

Primary port count

10

Storage relative humidity (H-H)

5 - 95 %

Switch type

Managed

Switching capacity

20 Gbit/s

Total Power over Ethernet (PoE) budget

110 W

Tehnilised andmed

Üksuse kalkuleeritud kaal

1.44 kg

Netokaal

0.55 kg

Laius

190 mm

Sügavus

106 mm

Kõrgus

30 mm

Mõõtmed (l x s x k)

190 mm × 106 mm × 30 mm

Toote kaal

550 g

Tehnilised andmed

Kiirpaigaldusjuhend

Jah
