COUGAR ATLAS 650 PSU, 80 plus Bronze, 650W (ATX 3.1)

Võimsus ja energiatarve

Sisendpinge

AC 100-240 V

.: Tehnilised andmed :.

Korpuse värv

Black

Toide

Toiteploki asukoht

Internal

Funktsioonid

Maksimaalne võimsus

650 W

Logistika andmed

Transpordikarbi brutokaal

2.05 kg

Transpordikarbi brutokaal

19 kg

Muud funktsioonid

Garantiiteave

Serial Number

Pakendi netokaal

1.8 kg

.: Pakendi andmed :.

Kogus pakendi kohta

1

Pakendi pikkus ( mm )

580 mm

Pakendi tüüp

Retail

Tehnilised andmed

+5V

20 A

Pack Width (mm)

158 mm

Box Width (mm)

495 mm

Box Height (mm)

185 mm

Circuit Protection

Over Voltage Undervoltage Over Temperature Over Current Short Circuit Protection Over Power

Input Power Connectors Quantity

1

Input Power Connectors Type

IEC-320 C14

Rated Input Current

10 A

Power Adapter and Power Supply Features

Active PFC

Modular Power Supply

Ei

+3.3V

20 A

Pack Height (mm)

165 mm

-12V

0.3 A (3.6 W)

+5VSB

3 A (15 W)

4/8-pin +12V Power Connector

2

4-pin Peripheral Power Connector

2

6/8-pin PCI Express Connector

2

+12V

54.1 A (649.2 W)

S-ATA Connector

6

16-pin PCI Express 5.0 (12VHPWR) Connector

1

24-pin Main Connector

1

Pack Length (mm)

187 mm

Power Device Type

Power Supply

Packs in Box

9

Depth (mm)

140 mm

Height (mm)

86 mm

Width (mm)

150 mm

Nominal Weight

1.8 kg

Warranty Products Returnable

Jah

80 PLUS Certification

80 Plus Bronze

Efficiency

87%

Input frequency

50/60 Hz
