UPS|EATON|520 Watts|650 VA|LineInteractive|5P650IRG2

.: Üldised andmed :.

Tootja koduleht

https://www.eaton.com/gb/en-gb/skuPage.5P650IRG2.html

Mudel

5P Gen2

.: Üldised omadused :.

Müratase

40 dB

.: Disain :.

Kokkuvõte

Eaton 5P650IRG2. UPS topology: Line-Interactive, Output power capacity: 0.65 kVA, Output power: 520 W. AC outlet types: C13 coupler, Power plug: C14 coupler, AC outlets quantity: 4 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Typical backup time at full load: 2 min, Typical backup time at half load: 9 min. Form factor: Rackmount, Product colour: Black, Rack capacity: 1U. Certification: IEC/EN 62040-1, UL 1778, IEC/EN 62040 -2 , IEC/EN 62040-3 (Performance), CE, CB report (TUV)

Kujutegur

Räkikinnitus

Toote värv

Must/Hõbedane

.: Pesad & liidesed :.

USB 2.0 portide arv

1

USB port

Jah

.: Aku & Toiteallikas :.

Akutehnoloogia

Sealed Lead Acid (VRLA)

Võimsus ja energiatarve

Output frequency

50/60 Hz

Väljundvõimsus

520 W

Logistika andmed

Kogus transpordikasti kohta

1

Töötingimused

Kasutamistemperatuur (T-T)

0 - 35 °C

.: Pakendi andmed :.

Max kogus transpordipakendis

1

Pakendi maht

0.04595 cubm

Transpordipakendi kaal

11.2 kg

Transpordipakendi kõrgus

17.5 cm

Transpordipakendi laius

44.5 cm

Transpordipakendi sügavus

59 cm

Tehnilised andmed

Mac compatibility

Ei

Hot-swap battery

Jah

Automatic battery test

Jah

Power plug

C14 coupler

Input connection type

IEC C14

Rack capacity

1U

Rack mount kit

Jah

Nominal output voltage

230 V

Waveform

Pure sine

AC outlets quantity

4 AC outlet(s)

AC outlet types

C13 coupler

Input operation voltage (min)

160 V

Safety

IEC/EN 62040-1, UL 1778

Unit Box Height

0.175

Unit Box Length

0.59

Unit Box Width

0.445

CnKood

85044095

Üksuse kalkuleeritud maht

0.04595 cubm

Number of input phases

1

Number of output phases

1

Management card included

Ei

ECO mode

Ei

RS-232 ports

1

UPS topology

Line-Interactive

Certification

IEC/EN 62040-1, UL 1778, IEC/EN 62040 -2 , IEC/EN 62040-3 (Performance), CE, CB report (TUV)

Efficiency

98 %

Input frequency

40/70 Hz

Input operation voltage (max)

294 V

Input ports

Single, IEC320 C14

Nominal input voltage

230 V

Output operation voltage (max)

240 V

Output operation voltage (min)

200 V

Output power capacity

0.65 kVA

Output power capacity, VA

650 VA

RS232

1

Topology

LineInteractive

Typical backup time at full load

2 min

Typical backup time at half load

9 min

USB

1

Tehnilised andmed

Üksuse kalkuleeritud kaal

11.2 kg

Netokaal

8.6 kg

Brutokaal

11.2 kg

Laius

438 mm

Sügavus

361 mm

Kõrgus

43.2 mm

Mõõtmed (l x s x k)

438 x 43.2 x 361mm

Toote kaal

8600 g

Tehnilised andmed

Ekraani tüüp

LCD

Tehnilised andmed

Kaasas tarkvara

Intelligent Power Software suite
