Mainboard|MSI|AMD X870E|SAM5|ATX|Memory DDR5|Memory slots 4|3xPCI-Express 16x|4xM.2|1xAudio-In|1xAudio-Out|4xUSB 2.0|2xUSB 3.2|3xUSB-C|1xRJ45|MAGX870ETOMAHAWKWIFI
Toode on läbimüüdud
Tellimine ei ole võimalik.
Msi X870 Tomahawk wifi title
MAG X870E TOMAHAWK WIFI is designed for gamers with a stable, durable and DIY friendly foundation for their PC builds. Coming up with true Wi-Fi 7 solution, 5G LAN, USB 40Gbps, PCIe 5.0 solutions, Supplemental PCIe Power, and exclusive EZ DIY features, it's ready for the battlefield of AMD Ryzen™ 9000 series processors.
MAG msi arsenal gaming
MSI's mainstream MAG series epitomizes stability and durability and is built to withstand the most intense gaming sessions. The entire lineup features robust construction with metallic-like hardness and excellent heat dissipation, ensuring stability for all critical gaming components.
- Supports AMD Ryzen™ 9000 / 8000 / 7000 Series Desktop Processors
- Supports DDR5 Memory, Dual Channel DDR5 8400+ MT/s (OC)
- Ultra Performance: 14+2+1 Duet Rail Power System, dual 8-pin CPU power connectors, Core Boost, Memory Boost, 8-layer PCB made by 2oz thickened copper and server-grade level material
- Frozr Guard: Extended Heatsink, MOSFET thermal pads rated for 7W/mK, additional choke thermal pads and EZ M.2 Shield Frozr II are built for high performance system and non-stop experience
- EZ DIY: EZ M.2 Shield Frozr II, EZ M.2 Clip II, EZ PCIe Release and EZ Antenna
- Lightning Fast Game experience: PCIe 5.0 slot, Lightning Gen 5 x4 M.2
- Ultra Connect: USB4 and 5G LAN with Wi-Fi 7 Solution - the latest solution for professional and multimedia use, delivering secure, stable, and high-speed networking and data transmission
- Audio Boost 5: Reward your ears with studio-grade sound quality for the most immersive gaming experience
Tootja
MSI
Tootekood
MAG X870E TOMAHAWK WIFI
EAN
4711377291927
Google link
lisainfo
Garantiiaeg
36 kuud
.: Disain :.
- Komponent
- PC
- Emaplaadi kujutegur
- ATX
- Kujutegur
- ATX
- Laius
- 243.84 mm
- Sügavus
- 304,8 mm
- PC tervise monitoorimine
- CPU, Ventilaator, Temperatuur, Pinge
.: Protsessor :.
- Protsessori tootja
- AMD
- Ühilduvad protsessoriseeriad
- AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
- Protsessori pesa
- SAM5
.: Kiibistik ( Chipset ) :.
- Emaplaadi kiibistik
- AMD
- Kiibistik ( Chipset)
- AMD X870E
- Emaplaadi kiip
- AMD X870E
.: Mälu :.
- Toetatud mälutüübid
- DDR5-SDRAM
- Sisemälu tüüp
- DDR5
- Mälupesa tüüp
- DIMM
- Toetatud mälu taktsagedused
- 4800,5600,8400 MHz
- Taktsagedus
- 4800/4866/4933/5000/5066/5100/5133/5200/5300/5333/5400/5500/5600/5800/6000/6200/6400/6600/6666/6800/7000/7200/7400/7467/7500/7600/7800/7900/7950/8000/8200/8266/8400 MHz
- Pesade arv
- 4
- Mälupesad
- 4
- Mälukanalid
- Kahe kanaliga
- Maksimaalne sisemälu
- 256 GB
Graafikakaart
- Integreeritud graafikaadapter
- Depending on CPU
.: Audio :.
- Intregeeritud helikaart
- Jah
- Audioväljundi kanalid
- 7.1 channels
.: Võrgustumine :.
- LAN-kontroller
- Realtek RTL8126
- Ethernet LAN
- 5 Gigabit
- Ethernet-liidese tüüp
- 5 Gigabit Ethernet
- WiFi
- Jah
- WiFi-standardid
- 802.11a/802.11b/802.11g/Wi-Fi 4 (802.11n)/Wi-Fi 5 (802.11ac)/Wi-Fi 6 (802.11ax)/Wi-Fi 6E (802.11ax)/Wi-Fi 7 (802.11be)
- Bluetooth
- Jah
- Bluetoothi versioon
- 5.4
Laienduspesad
- PCI Expressi x16 pesad
- 3
- PCI Expressi x16 (Gen 3.x) pesad
- 1
Kõvaketta tugi
- Kõvaketta ühenduse tüüp
- M.2, SATA III
- SATA
- Jah
- SATA-ühenduste arv
- 0
- SATA II ühenduste arv
- 0
- SATA III ühenduste arv
- 4
- SATA 3.0
- Jah
- M.2 (M) siinide arv
- 4
- RAID
- SATA 0, 1, 10
Sisemine I/O moodul
- EPS-toitepistmik (8 kontakti)
- Jah
- ATX-toitepistmik (24 kontakti)
- Jah
- CPU-ventilaatori pistmik
- Jah
- USB 2.0 pistmikud
- 4
- TPM-ühenduspesa
- Header
Tagapaneeli I/O pesad
- VGA (D-Sub) portide arv
- 0
- HDMI-portide arv
- 1
- DVI-D liideste arv
- 0
- Audioväljund
- 1
- S/PDIF-väljund
- Jah
- Audio sisend
- 1
- Mikrofonisisend
- Jah
- USB 2.0 portide arv
- 4
- USB 2.0
- Jah
- Ethernet LAN (RJ-45) pordid
- 1
.: Kaal ja mõõtmed :.
- Brutokaal
- 2.25 kg
- Netokaal
- 1.8 kg
.: Pakendi andmed :.
- Max kogus transpordipakendis
- 1
- Pakendi maht
- 0.006641 cubm
Muud näitajad
- DisplayPort versioon
- 1.4
- Compatible processor series
- AMD Ryzen 7000 Series/AMD Ryzen 8000 Series/AMD Ryzen 9000 Series
- Supported processor sockets
- Pesa AM5
- ATX Power connector (24-pin)
- Jah
- EPS power connector (8-pin)
- Jah
- Memory slots type
- DIMM
- Motherboard chipset family
- AMD
- S/PDIF out port
- Jah
- Supported memory types
- DDR5-SDRAM
- Memory channels
- Dual-channel
- CPU fan connector
- Jah
- Number of SATA III connectors
- 4
- PCI Express x16 (Gen 3.x) slots
- 1
- Number of M.2 (M) slots
- 4
- Number of storage drives supported
- 8
- Supported storage drive types
- HDD & SSD
- Supported storage drive interfaces
- M.2,SATA III
- Processor manufacturer
- AMD
- DisplayPort arv
- 2
- USB 3.2
- Jah
- USB 3.2 Gen 1 (3.1 Gen 1) A-tüüpi portide hulk
- 3
- USB 3.2 Gen 2 (3.1 Gen 2) C-tüüpi portide hulk
- 1
- USB 3.2 Gen 1 (3.1 Gen 1) pistmikud
- 4
- USB 3.2 Gen 1 (3.1 Gen 1) C-tüüpi portide hulk
- 0
- USB 3.2 Gen 2 (3.1 Gen 2) konnektorid
- 1
- PCI Express x16 (Gen 4.x) slots
- 1
- PCI Express x16 (Gen 4.x) pilud
- 1
- USB4 Gen 2x2 portide arv
- 1
- PCI Express x16 (Gen 5.x) slots
- 1
- PCI Express x16 (Gen 5.x) slotid
- 1
- Supported memory clock speed (max)
- 8400 MHz
- Unit Box Height
- 0.275
- Unit Box Length
- 0.345
- Unit Box Width
- 0.07
- CnKood
- 84733020
- Toetatud mälu taktsageduse kiirus (maks)
- 8400 MHz
- ECC сompatibility
- Non-ECC
- ECC ühilduvus
- Mitte-ECC
- 4. M.2 suurim võtme suurus
- 2280
- Üksuse kalkuleeritud maht
- 0.007666 cubm
- Üksuse kalkuleeritud kaal
- 2.39 kg
- Kokkuvõte
- MSI MAG X870E TOMAHAWK WIFI. Processor manufacturer: AMD, Processor socket: Socket AM5, Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series. Supported memory types: DDR5-SDRAM, Maximum internal memory: 256 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, SATA III, Supported storage drive types: HDD & SSD. Ethernet interface type: 5 Gigabit Ethernet, LAN controller: Realtek RTL8126, Top Wi-Fi standard: Wi-Fi 7 (802.11be). Component for: PC, Motherboard form factor: ATX, Motherboard chipset family: AMD
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
- 3
- On-board graphics card
- Ei
- Top Wi-Fi standard
- Wi-Fi 7 (802.11be)
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
- 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
- 2
- Total number of SATA connectors
- 4
- Number of HDDs supported
- 4
- USB4 Gen 2x2 ports quantity
- 1
- USB 3.2 Gen 1 (3.1 Gen 1) connectors
- 4
- PC health monitoring
- CPU/Fan/Temperature/Voltage
- USB 3.2 Gen 2 (3.1 Gen 2) connectors
- 1
- Tootja koduleht
- https://www.msi.com/Motherboard/MAG-X870E-TOMAHAWK-WIFI
- HDMI versioon
- 2.1
- Mudel
- MAG X870E TOMAHAWK WIFI
- USB 3.2 Gen 2 (3.1 Gen 2) A-tüüpi portide hulk
- 2
- 4. M.2 kõrgeima PCI Expressi põlvkonna M.2
- 4.0
- 1st M.2 largest key size
- 22110
- 1. M.2 suurim võtme suurus
- 22110
- 1st M.2 highest PCI Express generation
- 5.0
- 1. M.2 kõrgeima PCI Expressi põlvkonna M.2
- 5.0
- 2nd M.2 largest key size
- 2280
- 2. M.2 suurim võtme suurus
- 2280
- Component for
- PC
- 2nd M.2 highest PCI Express generation
- 5.0
- 2. M.2 kõrgeima PCI Express põlvkonna M.2
- 5.0
- 3rd M.2 largest key size
- 2280
- 3. M.2 suurim võtme suurus
- 2280
- Transpordipakendi kaal
- 2.248 kg
- 3rd M.2 highest PCI Express generation
- 4.0
- 3. M.2 kõrgeima PCI Express põlvkonna M.2
- 4.0
- Transpordipakendi kõrgus
- 27.5 cm
- 4th M.2 largest key size
- 2280
- Transpordipakendi laius
- 7 cm
- mSATA-pesade arv
- 0
- 4th M.2 highest PCI Express generation
- 4.0
- Transpordipakendi sügavus
- 34.5 cm
- Kogus transpordikasti kohta
- 5
- Toetatud kõvaketaste arv
- 4
- Protsessori poolt toetatud maksimaalne operatiivmälu
- 256 GB
- Toetatud ketaste tüübid
- HDD & SSD
- Toetatud ketaste arv
- 8
- HDMI-versioon
- 2.1
- DisplayPorts quantity
- 2
- SATA-ühenduste koguarv
- 4
- Ethernet interface type
- 5 Gigabit Ethernet
- Ethernet LAN (RJ-45) ports
- 1
- Toote värv
- Must
- Microphone in
- Jah
- Motherboard chipset
- AMD X870E
- Toetatud protsessoripesad
- Protsessoripesa AM5
- LAN controller
- Realtek RTL8126
- Maximum internal memory supported by processor
- 256 GB
- Number of memory slots
- 4
- Processor Socket
- Pesa AM5
- Supported memory clock speeds
- 4800/5600/8400 MHz
- USB 2.0 connectors
- 4
- USB-C
- Jah
