*80 Plus Bronze with peak 88% efficiency * Hybrid Modular Cabling Design makes system upgrade and replacement easy* Anti3s Q-Brick design protects power supply from shock, static electricity, and slip * Hydraulic Bearing Fan delivers silent, cooling, and durable performance* High efficiency +5Vsb circuit helps system meet EU ErP Lot 6 standard (lower than 1W power consumption at standby mode) * Double Forward circuit design provides high efficiency*Active PFC universal switching circuit improves Power Factor value up to 0.99* Powerful single +12V design provides maximum power and compatibility to latest CPUs and high-end graphics cards * Over Power, Over Voltage, and Short-circuit protection provide great safety to your system
| Tootja | Lepa |
| Tootekood | B800-MB |
| EAN | 4710445320958 |
| Google link | lisainfo |
| Garantiiaeg | 24 kuud |
| .: Disain :. | |
| Kujutegur | ATX |
| Toote värv | Black, Red |
| Võimsus ja energiatarve | |
| Sisseehitatud aku | Ei |
| Sisendsagedus | 47/63 Hz |
| Sisendvool | 6 - 12 A |
| .: Tehnilised andmed :. | |
| Garantii | 24 |
| Toide | |
| AC (toide) sisend | LEPA 80+ Bronze power supply - 800 Watt, DC output +12V- 65A/780W W |
| Funktsioonid | |
| Vahelduvvoolu pinge | 100 - 240 V |
| Töötingimused | |
| Kasutamistemperatuur (T-T) | 0 - 40 °C |
| .: Pakendi andmed :. | |
| Pakenditaara kaal | 0.28 kg |
| Pakendi maht | 0.01 m³ |
| Kogus pakendi kohta | 4.00 pc(s) |
| Pakendi sügavus | 380.00 mm |
| Pakendi laius ( mm ) | 220.00 mm |
| Pakendi kõrgus ( mm ) | 120 mm |
| Fan function | 135 mm fan |
| ATX version | 2.3 |
| EPS version | 2.92 |
| WEEE tax | Ei |
| Tare weight master carton | 1.90 kg |
| Gross depth master carton | 470.00 mm |
| Gross width master carton | 290.00 mm |
| Gross height master carton | 310.00 mm |
| Plastic (No PET) | 180 g |
| Net weight master carton | 10.40 kg |
| Paper/Pasteboard | 645.00 g |
| ATX power connector (20+4 pin) | Y |
| Connector(s) | 1 x main power 20+4 pin ATX ¦ 1 x 8P CPU¦ 1 x 4+4P CPU ¦ 4x 6+2P PCI Express power ¦ 12 x 15 pin Serial ATA power ¦ 4 x 4 PIN internal power ¦ 1 x 4 PIN mini-power connector |
| CPU power connector (4+4 pin) | Y |
| CPU power connectors (8-pin) | 1 |
| DC output voltage | +12V, +3.3V, +5V, +5 |
| Floppy disk drive connector | Y |
| Floppy drive power connector | 1 |
| Motherboard power connector | 20+4 pin ATX |
| Number of SATA power connectors | 12 |
| PCI Express connector | Y |
| PCI Express power connectors (6+2 pin) | 4 |
| Peripheral (Molex) power connectors (4-pin) | 4 |
| Power Factor Correction (PFC) type | Active |
| Power protection features | Over power, Over vol |
| Product codename | B800-MB |
| Purpose | PC |
| 80 PLUS Certification | 80 PLUS Bronze |
| Cabling Type | Modular |
| Combined power (+12V) | 792 W |
| Combined power (+3.3V) | 130 W |
| Combined power (+5V) | 130 W |
| Combined power (+5Vsb) | 15 W |
| Combined power (-12V) | 9.6 W |
| Efficiency | 88 % |
| Fan | 135 mm fan |
| Fan Diameter | 140 cm |
| Max output current (+12V) | 66 A |
| Max output current (+3.3V) | 25 A |
| Max output current (+5V) | 25 A |
| Max output current (+5Vsb) | 3 A |
| Max output current (-12V) | 0.8 A |
| Mean time between failures (MTBF) | 100000 h |
| Nominal power | 800 W |
| Power factor | 0.99 |
| Laius | 150 cm |
| Sügavus | 165 cm |
| Kõrgus | 86 cm |
| Toote kaal | 2030 oz |
| Mõõdud (l x s x k) | 165(L) x150(W) x86(H) mm |
| Brutokaal | 2.88 kg |
| Netokaal | 2.60 |
