Overview
TL-SG105PP-M2 is an unmanaged switch with 5 Gigabit ports that requires no configuration and provides 4 PoE (Power over Ethernet) ports. It can automatically detect and supply power with all IEEE 802.3af/at/bt compliant Powered Devices (PDs) at port 1-4. In this situation, the electrical power is transmitted along with data in one single cable allowing you to expand your network to where there are no power lines or outlets, where you wish to fix devices such as APs, IP Cameras or IP Phones, etc.
The 2.5G ports support automatic negotiation to 10Mbps/100Mbps/1Gbps/2.5Gbps according to the type of connected device and provide sufficient bandwidth to unlock the highest performance of 2.5G/Multi-Gigabit devices, including NAS, a personal workstation, 8K video stream, and 2.5G Wi-Fi 6 AP.
Power Over Ethernet
4 RJ45 ports (port 1 to port 4) of the switch support Power over Ethernet (PoE) function. They can automatically detect and supply power with those connected IEEE 802.3af/at/bt compliant Powered Devices (PDs).
Overload Arrangement
TL-SG105PP-M2 has the priority function which will help protect the system when the system power is overloaded. If all PoE PDs power consumption is ≥ 123 W*, a priority will be arranged among the PoE ports, then the system will cut off the power of the lowest-priority port.
Intelligent Power Management
Priority (port 1 > port 2 > port 3 > port 4): This function will help protect the system when the system power is overloaded. For example, port 2, 3, and 4 is using 35 W respectively (maximum power per port is 60 W); the system power is 105W in total. If there is an additional PD inserted to port 1 with 23 W, and then the system will cut off the power of port 4 because of the overloaded power, this means port 1 will use 23 W respectively and port 2&3 will use 35 W, no power will be supplied to port 4.
Highlight Performance
- With PoE Auto Recovery, the switch will constantly detect the data transmission with PoE-powered devices (PD) for port 1-4. When the switch finds that a PD stops sending data packets to the switch for a long period, the switch will reboot it automatically.
- Provides super-fast connections to 2.5G NAS, Server, 2.5G PCIe Adapter/ NIC, gaming computer, 2.5G WiFi 6 AP, 8K video, and more.
- Auto-negotiation for 10Mbps/100Mbps/1Gbps/2.5Gbps connections provide optimal performance.
TL-SG105PP-M2 is easy to install and use. It requires no configuration and installation. With desktop and wall mountable design, outstanding performance and quality, the TP-Link 5-Port 2.5G Desktop Switch with 4-Port PoE++ TL-SG105PP-M2 is a great selection for expanding your network.
| Tootja | TP-LINK |
| Tootekood | TL-SG105PP-M2 |
| EAN | 4895252501131 |
| Google link | lisainfo |
| Garantiiaeg | 36 kuud |
| .: Üldised andmed :. | |
| Tootja koduleht | https://www.tp-link.com/sg/business-networking/unmanaged-switch/tl-sg105pp-m2/ |
| .: Üldised omadused :. | |
| Automaatne ühildumine | Jah |
| .: Disain :. | |
| Toote värv | Black |
| Korpuse materjal | Teras |
| LED-indikaatorid | Jah |
| Toote värv | Must |
| LED-indikaatorid | Jah |
| .: Toimimine :. | |
| Ilma ventilaatorita | Jah |
| .: Võrgustumine :. | |
| IGMP-jälgimine | Jah |
| Võrgustandardid | IEEE 802.1p/IEEE 802.3/IEEE 802.3ab/IEEE 802.3u/IEEE 802.3x |
| Automaatse MAC-aadressi aegumise tugi | Jah |
| Automaatse MAC-aadressi tuvastamise tugi | Jah |
| IGMP-jälgimine | Jah |
| Võrgustandardid | IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x |
| Voo reguleerimise tugi | Jah |
| Auto MDI/MDI-X | Jah |
| 10G-tugi | Ei |
| .: Pesad & liidesed :. | |
| 2.5G Ethernet (copper) ports quantity | 5 |
| 2,5G Etherneti (vask) portide arv | 5 |
| Installitud SFP moodulite hulk | 0 |
| Installitud SFP+ moodulite hulk | 0 |
| Etherneti vaskkaablite tehnoloogia | 10BASE-T, 100BASE-TX, 1000BASE-T |
| RJ-45 Etherneti ühenduse pesade arv | 5 |
| RJ-45 Etherneti ühenduse pesade tüüp | Gigabit Ethernet (10/100/1000) |
| Võimsus ja energiatarve | |
| Sisendpinge | 53.5 V |
| Sisendvool | 2.43 A |
| Power over Ethernet (PoE) | Jah |
| Sisendsagedus | 50 Hz |
| AC-sisendpinge | 220 V |
| AC-sisendsagedus | 50 Hz |
| Elektritarbimine (max) | 143,37 W |
| Toiteallikate arv | 1 |
| .: Tehnilised andmed :. | |
| Püstikmontaaž | Ei |
| Andmeedastus | |
| Edastamise kiirus | 18,6 Mpps |
| Ladusta-ja-edasta | Jah |
| MAC-aadresside tabel | 4000 sisestust |
| Lülitusvõime | 25 Gbit/s |
| Juhtimisfunktsioonid | |
| Teenusekvaliteedi (QoS) tugi | Jah |
| Lüliti tüüp | Mittejuhitav |
| Teenusekvaliteedi (QoS) tugi | Jah |
| Toide | |
| Kaasas toiteplokk | Jah |
| Toiteallikas | DC/PoE |
| Toiteallikas | External |
| Ethernet LAN-funktsioonid | |
| IEEE 802.1p | Jah |
| IEEE 802.3af | Jah |
| IEEE 802.3at | Jah |
| IEEE 802.3x | Jah |
| Funktsioonid | |
| Vahelduvvoolu pinge | 220 V |
| Toetatud kaablitüübid | Cat3, Cat4, Cat5, Cat5e |
| Mudeli originaalnimi | TL-SG105PP-M2 |
| Internet elektrivõrgu kaudu (PoE) | |
| Toide üle võrgu (PoE) võimsus pordi kohta | 60 W |
| Etherneti toitega 4PPoE (PoE++) portide kogus | 4 |
| Toide üle võrgu (PoE) võimsusühikuid kokku | 123 W |
| Power over Ethernet tugi | Jah |
| Logistika andmed | |
| Kogus transpordikasti kohta | 1 |
| Töötingimused | |
| Suhteline õhuniiskus (H-H) hoiustamisel | 5 - 90 protsenti |
| Hoiustamistemperatuur (T-T) | -40 - 70 °C |
| Soojuse hajumine | 488,89 BTU/h |
| Kasutamistemperatuur (T-T) | 0 - 40 °C |
| Suhteline õhuniiskus kasutamisel (H-H) | 10 - 90 protsenti |
| Suhteline õhuniiskus kasutamisel (H-H) | 10 - 90 % |
| Hoiustamistemperatuur (T-T) | -40 - 70 °C |
| .: Pakendi andmed :. | |
| Kasutusjuhend | Jah |
| Pakendi tüüp | Box |
| Kaablid kaasa arvatud | AC |
| ◁ SERTIFIKAADID ▷ | |
| Sertifikaat | CE, FCC, RoHS |
| User guide | Jah |
| Rack mounting | Ei |
| Store-and-forward | Jah |
| 10G support | Ei |
| Basic switching RJ-45 Ethernet ports quantity | 5 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Flow control support | Jah |
| Copper ethernet cabling technology | 1000BASE-T/100BASE-TX/10BASE-T |
| Fanless | Jah |
| 2.5GbE | 5 |
| Unit Box Height | 0.24 |
| Unit Box Length | 0.32 |
| Unit Box Width | 0.07 |
| Unit Calculated Volume | 0.005376 cubm |
| Product Net Weight | 1.2 kg |
| Unit Calculated Weight | 1.52 kg |
| Summary | TP-Link 5-Port 2.5G Desktop Switch with 4-Port PoE++. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 5. MAC address table: 4000 entries, Switching capacity: 25 Gbit/s. Networking standards: IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x. Power over Ethernet (PoE) |
| Cable types supported | Cat3/Cat4/Cat5/Cat5e |
| MAC address auto-aging supported | Jah |
| MAC address auto-learning supported | Jah |
| Power over Ethernet 4PPoE (PoE++) ports quantity | 4 |
| Power supply included | Jah |
| Auto-negotiation | Jah |
| Certification | CE, FCC, RoHS |
| Desktop/pedestal | Jah |
| Forwarding rate | 18.6 Mpps |
| Heat dissipation | 488.89 BTU/h |
| Housing material | Steel |
| MAC address table | 4000 entries |
| Power over Ethernet (PoE) power per port | 60 W |
| Power Source | DC/PoE |
| Storage relative humidity (H-H) | 5 - 90 % |
| Switch type | Unmanaged |
| Switching capacity | 25 Gbit/s |
| Total Power over Ethernet (PoE) budget | 123 W |
| Laius | 209 mm |
| Laius | 209 mm |
| Sügavus | 126 mm |
| Kõrgus | 26 mm |
| Mõõtmed (l x s x k) | 209×126×26 mm |
| Sügavus | 126 mm |
| Kõrgus | 26 mm |
