Dual 2.5 Gbps Ports, Engineered for Dense Environments
Delivering high-speed transmissions through dual 2.5 Gbps ports, ER707-M2 is designed for multi-person environments such as retail stores, hotels, and offices. Enjoy a blazing-fast network experience while working from home.
6× WAN Ports & 1 USB WAN for Mobile Broadband
Empowered with up to 6× WAN SFP and RJ45 ports, ER707-M2 supports various internet access.△ Multi-WAN Load Balancing distributes data streams based on the bandwidth proportion of every WAN port to increase the utilization rate of multi-line broadband.
Connect a 4G/3G modem to the USB 2.0 port for a LTE WAN backup.
High-Security VPN
Pass-through traffic and a variety of VPN protocols, such as SSL, GRE§, IPSec, PPTP, and L2TP, are available on ER707-M2, giving consumers versatile options. One-click auto IPSec VPN simplifies VPN configuration and facilitates network management and deployment.* The router also features a built-in hardware engine to boost VPN performance.
Internet Access Management Strategy
Standardize users’ online behavior and easily specify the internet access rights and strategies of employees via IP/MAC/URL Filtering and Access Control List (ACL). Captive Portal authentication facilitates network resource control by capturing, authenticating, and classifying user access. Appropriate network resources can also be allocated for particular users or guests.
Omada SDN—The Smarter Cloud Solution for Business Networking
As the router that seamlessly integrates into the Omada Software Defined Networking (SDN) platform, ER707-M2 allows for remote and centralized management, anywhere, anytime. Standalone management via the Web UI or app is also available to maximize convenience.
Easy Management with the Omada App
Follow configuration instructions on the free Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status and manage clients, all from the convenience of a smart phone or tablet.
| Tootja | TP-LINK |
| Tootekood | ER707-M2 |
| EAN | 4895252500738 |
| Google link | lisainfo |
| Garantiiaeg | 36 kuud |
| .: Üldised andmed :. | |
| Seadme tüüp | Router |
| Tootja koduleht | https://www.tp-link.com/uk/business-networking/omada-sdn-router/er707-m2/ |
| .: Üldised omadused :. | |
| Jõudlus | 1,44 Gbit/s |
| Välkmälu | 128 MB |
| Välkmälu | 128 MB |
| .: Disain :. | |
| Toote värv | Black |
| Korpuse materjal | Teras |
| LED-indikaatorid | LAN, Link, Võimsus, Kiirus, Süsteem, USB, WAN |
| Seinale kinnitatav | Jah |
| Toote värv | Must |
| LED-indikaatorid | LAN/Link/Power/Speed/System/USB/WAN |
| .: Mälu :. | |
| Paigaldatud operatiivmälu | 1000 MB |
| .: Võrgustumine :. | |
| Võrgustandardid | IEEE 802.1Q/IEEE 802.3/IEEE 802.3ab/IEEE 802.3q/IEEE 802.3u/IEEE 802.3x |
| VLAN-i tugi | Jah |
| Võrguaadresside transleerimine (NAT) | Jah |
| Võrgustandardid | IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3q, IEEE 802.3u, IEEE 802.3x |
| Ethernet LAN-i andmeedastuskiirused | 10,100,1000,2500 Mbit/s |
| VLAN-i tugi | Jah |
| Ethernet LAN-i andmeedastuskiirused | 10/100/1000/2500 Mbit/s |
| .: Pesad & liidesed :. | |
| WAN-portide arv | 1 |
| WAN/Ethernet LAN-portide arv | 6 |
| Installitud SFP moodulite hulk | 1 |
| Ethernet LAN (RJ-45) pordid | 6 |
| USB versioon | 2.0 |
| .: Aku & Toiteallikas :. | |
| Toiteallika tüüp | DC (alalisvool) |
| Toiteallika tüüp | DC |
| Võimsus ja energiatarve | |
| Väljundpinge | 12 V |
| Väljundvool | 1,5 A |
| Turvalisus | |
| Turvaalgoritmid | 128-bit AES/192-bit AES/256-bit AES/3DES/DES/MD5/SHA-1/SNMP/SNMPv2/SNMPv3 |
| ICMP rünnaku ennetamine | Jah |
| ICMP attack prevention | Jah |
| Pääsuloend (ACL) | Jah |
| VPN-tunnelite arv | 66 |
| URL-i filtreerimine | Jah |
| Turvaalgoritmid | 3DES, 128-bit AES, 192-bit AES, 256-bit AES, DES, MD5, SHA-1, SNMP, SNMPv2, SNMPv3 |
| Protokollid | |
| DHCP-klient | Jah |
| DHCP-klient | Jah |
| DHCP-server | Jah |
| DMZ-tugi | Jah |
| .: Tehnilised andmed :. | |
| Reeglipõhine marsruutimine | Jah |
| Sustainability compliance | Jah |
| Jätkusuutlikkuse järgimine | Jah |
| Compliance certificates | CE/Federal Communications Commission (FCC)/RoHS |
| Vastavussertifikaadid | CE, Föderaalne kommunikatsioonikomisjon (FCC), RoHS |
| Policy-based routing | Jah |
| Sisemälu tüüp | DDR4 |
| Andmeedastus | |
| Static route | Jah |
| Staatiline ruutimine | Jah |
| Juhtimisfunktsioonid | |
| Veebipõhine haldus | Jah |
| Universaalne Plug and Play (UPnP) | Jah |
| Veebipõhine haldus | Jah |
| Süsteemisündmuste logi | Jah |
| Universaalne Plug and Play (UPnP) | Jah |
| Ethernet LAN-funktsioonid | |
| 10/100/1000M | 4 |
| Ergonoomika | |
| Lähtestusnupp | Jah |
| Lähtestusnupp | Jah |
| Logistika andmed | |
| Kogus transpordikasti kohta | 1 |
| Muud funktsioonid | |
| Ethernet-liidese tüüp | 2.5 Gigabit Ethernet, Kiire Ethernet, Gigabit Ethernet |
| Toetatud võrguprotokollid | TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, SNMP |
| USB-portide hulk | 1 |
| .: Toetatud operatsioonisüsteemid :. | |
| Toetatud Windowsi operatsioonisüsteemid | Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP |
| Toetatud Linuxi operatsioonisüsteemid | Jah |
| Toetatud Maci operatsioonisüsteemid | Jah |
| Töötingimused | |
| Suhteline õhuniiskus (H-H) hoiustamisel | 5 - 90 protsenti |
| Hoiustamistemperatuur (T-T) | -40 - 70 °C |
| Kasutamistemperatuur (T-T) | 0 - 40 °C |
| Suhteline õhuniiskus kasutamisel (H-H) | 10 - 90 protsenti |
| Suhteline õhuniiskus kasutamisel (H-H) | 10 - 90 % |
| Hoiustamistemperatuur (T-T) | -40 - 70 °C |
| WAN-ühendus | |
| Ethernet WAN | Jah |
| SFP WAN | Jah |
| .: Pakendi sisu :. | |
| Kiirpaigaldusjuhend | Jah |
| Kiirpaigaldusjuhend | Jah |
| AC-adapter kaasa arvatud | Jah |
| .: Pakendi andmed :. | |
| Pakendi sügavus | 323 mm |
| Pakendi laius ( mm ) | 242 mm |
| Pakendi kõrgus ( mm ) | 73 mm |
| Pakendi kaal | 1,1 kg |
| Linux operating systems supported | Jah |
| Supported network protocols | TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, SNMP |
| Wall mountable | Jah |
| System event log | Jah |
| DMZ support | Jah |
| DHCP server | Jah |
| URL filtering | Jah |
| Access Control List (ACL) | Jah |
| LAN \ WAN ports | 2 |
| VPN tunnels quantity | 66 |
| 2.5GbE | 1 |
| Unit Box Height | 0.065 |
| Unit Box Length | 0.275 |
| Unit Box Width | 0.25 |
| SPF | 1 |
| Unit Calculated Volume | 0.004469 cubm |
| Product Net Weight | 1.2 kg |
| Unit Calculated Weight | 1.5 kg |
| Summary | TP-Link Omada Multi-Gigabit VPN Router. Networking standards: IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3q, IEEE 802.3u, IEEE 802.3x, Ethernet interface type: 2.5 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000,2500 Mbit/s. Supported network protocols: TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, SNMP. Security algorithms: 3DES, 128-bit AES, 192-bit AES, 256-bit AES, DES, MD5, SHA-1, SNMP, SNMPv2, SNMPv3. Compliance certificates: CE, Federal Communications Commission (FCC), RoHS. Flash memory: 128 MB, Internal memory: 1000 MB, Internal memory type: DDR4 |
| Installed SFP modules quantity | 1 |
| WAN ports quantity | 1 |
| WAN/Ethernet LAN ports quantity | 6 |
| Network address translation (NAT) | Jah |
| Ethernet interface type | 2.5 Gigabit Ethernet/Fast Ethernet/Gigabit Ethernet |
| Ethernet LAN (RJ-45) ports | 6 |
| Mac operating systems supported | Jah |
| Windows operating systems supported | Windows 10/Windows 2000/Windows 7/Windows 8/Windows 8.1/Windows 98SE/Windows NT/Windows Vista/Windows XP |
| Housing material | Steel |
| Output current | 1.5 A |
| Output Voltage | 12 V |
| Package depth | 323 mm |
| Package height | 73 mm |
| Package weight | 1100 g |
| Package width | 242 mm |
| Storage relative humidity (H-H) | 5 - 90 % |
| Throughput | 1.44 Gbit/s |
| USB 2.0 | 1 |
| Laius | 226 mm |
| Laius | 226 mm |
| Sügavus | 131 mm |
| Kõrgus | 35 mm |
| Mõõtmed (l x s x k) | 226 × 131 × 35 mm |
| Sügavus | 131 mm |
| Kõrgus | 35 mm |
