TP-Link VIGI InSight S345ZI Kuul (kuju) IP süsteemiga turvakaamera Hooneväline 2688 x 1520 pikslit Sein

.: Üldised andmed :.

Seadme tüüp

IP security camera

Tootja koduleht

https://www.tp-link.com/in/business-networking/vigi-network-camera/insight-s345zi/#highlights

.: Disain :.

Toote värv

White

Kujutegur

Bullet

.: Mälu :.

Ühilduvad mälukaardid

MicroSD (TransFlash)

.: Audio :.

Toetatud audioformaadid

G.711 A-law

.: Kaamera :.

Lens viewing angle, vertical

16.8-53.8 °

.: Võrgustumine :.

Võrgustandardid

IEEE 802.3af/IEEE 802.3at

Web browser

Jah

Ethernet LAN

Jah

Bluetooth

Ei

.: Pesad & liidesed :.

DC-pistik

Jah

Audioväljund

1

Ethernet LAN (RJ-45) pordid

1

.: Aku & Toiteallikas :.

Toiteallika tüüp

DC,PoE

Pildisensor

Progressiivne skaneerimine

Jah

Juhtimisfunktsioonid

Veebipõhine haldus

Jah

Objektiivi süsteem

Lens viewing angle, diagonal

34.1-122.8 °

Lens viewing angle, horizontal

29.6-102 °

Öövaatluse funktsioon

Öönägemine

Jah

Toide

Toitenõuded

12V DC ± 5%, Max.10.8 W, 5.5 mm Coaxial Power Plug, PoE: 802.3af/at, class 0, Max.12 W

Voolutarve

12 Watts

Ergonoomika

Pöördenurga ulatus

360 °

Lähtestusnupp

Jah

Logistika andmed

Kogus transpordikasti kohta

1

Muud funktsioonid

Toetatud resolutsioonid

1920 x 1080 (HD 1080)/2048 x 1280/2304 x 1296/2560 x 1440/2688 x 1520

Töötingimused

Kasutamistemperatuur (T-T)

-30 - 60 °C

Suhteline õhuniiskus kasutamisel (H-H)

0 - 95 %

Hoiustamistemperatuur (T-T)

-40 - 60 °C

.: Pakendi andmed :.

Max kogus transpordipakendis

1

Pakendi maht

0.006588 cubm

Transpordipakendi kaal

1.451 kg

Transpordipakendi kõrgus

13.5 cm

Transpordipakendi laius

16 cm

Transpordipakendi sügavus

30.5 cm

Tehnilised andmed

Password protection

Jah

Placement supported

Outdoor

Supported network protocols

TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP

Number of cameras

1

IP address filtering

Jah

Image quality adjustment

Brightness/Contrast/Mirror/Saturation/Sharpness

Wide Dynamic Range (WDR)

Jah

Live view

Jah

Motion sensor

Jah

Sample rate

8 kHz

Video motion detection

Jah

Number of illumination LEDs

4

LED type

IR

Number of microphones

1

Remote viewing

Jah

Alert notification type

Push notification

HTTPS encryption

Jah

Infra-red wavelength

850 nm

Supports card capacities up to

512GB

Unit Box Height

0.135

Unit Box Length

0.305

Unit Box Width

0.16

CnCode

85258900

Unit Calculated Volume

0.006588 cubm

Unit Calculated Weight

1.45 kg

Summary

TP-Link VIGI InSight S345ZI. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Wall, Product colour: White, Form factor: Bullet. Angle of rotation: 360°, Lens viewing angle, horizontal: 29.6–102, Lens viewing angle, vertical: 16.8–53.8. Sensor type: CMOS, Optical sensor size: 25.4 / 2.9 mm (1 / 2.9"). Optical zoom: 5x, Focal length range: 2.7 - 13.5 mm, Focus: Motorized

Tilt angle range

0 - 90 °

Back Light Compensation (BLC)

Jah

Digital Wide Dynamic Range (DWDR)

Jah

Highlight Compensation (HLC)

Jah

Noise reduction technology

3D noise reduction

Smart IR

Jah

Mirror

Jah

Number of lenses

1

Digest authentication

Jah

Number of simultaneous live view channels

6 channels

Human and vehicle targets classification

Jah

Infrared (IR) cut-off filter

Jah

Region of Interest (ROI) encoding

Jah

Focal length range

2.7 - 13.5 mm

Weatherproof

Jah

Dynamic range

120 dB

Bit rate control

Constant Bit Rate (CBR)/Variable Bit Rate (VBR)

Audio input channels

1.0 channels

Bit rate range

0 - 64 Kbit/s

Power consumption (Power over Ethernet (PoE))

12 W

Cloud-managed

Jah

Alarm input channels

1

Alarm output channels

1

Audio detection

Jah

Detect distance (tele)

207 m

Detect distance (wide)

66 m

Identify distance (tele)

21 m

Identify distance (wide)

7 m

Observe distance (tele)

86 m

Observe distance (wide)

28 m

Recognize distance (tele)

41 m

Recognize distance (wide)

13 m

Built-in siren

Jah

Day/night mode

Jah

DC output voltage

12

Ethernet LAN (RJ-45) ports

1

Maximum aperture number

1.6

Mounting type

Wall

Noise reduction

Jah

Protection features

Waterproof

Sensor type

CMOS

Video compression formats

H.264/H.264+/H.265/H.265+

Video recording

Jah

Zoom capability

Jah

Audio system

2-way

Bit rate

Main Stream: 256 Kbps to 6 Mbps, Sub-Stream: 512 Kbps to 1024 Kbps

Built-in microphone

Jah

Camera design

Bullet

Camera shutter speed

1/3 to 1/10000 s

Connectivity Technology

Wired

Environment

Outdoor

Focal Length

2.7-13.5 mm

Focus

Motorized

Housing material

Metal

Lens Mount

M14

Maximum memory card size

512 GB

Min. Illumination

0.005 Lux

Network Camera Type

HDTV/Megapixel/Outdoor

Night vision distance

10 m

Operating temperature range

-30–60 °C

Optical sensor size

1/2.9 "

Optical Zoom

5 x

Pan range

0 - 360 °

Pixel Resolution

4 Mega Pixel

Power Options

12V/PoE

Resolution

4 Mega Pixel

Sensor size

1/2.9”

Signal-to-Noise Ratio (SNR)

52 dB

Storage relative humidity (H-H)

0 - 95 %

Total megapixels

4 MP

Video streaming

Jah

Tehnilised andmed

Netokaal

1.04 kg

Netokaal

1.04 kg

Brutokaal

1.45 kg

Laius

100 mm

Kõrgus

101 mm

Mõõtmed (l x s x k)

256 × 100 × 101 mm

Toote kaal

1040 g

Pikkus

256 mm
